Introduction to ABB XVC724BE101 3BHE009017R0101

Name: 3BHE009017R0101 ABB XVC724BE101 analog input module
SKU: 5709
Price: 1399.00 USD
Availability: InStock

3BHE009017R0101 Product Overview

The ABB XVC724BE101 (order code: 3BHE009017R0101) is a high-precision analog input module, specifically engineered for ABB’s Ability™ System 800xA and AC 800M distributed control systems (DCS). It specializes in converting continuous analog signals from industrial sensors (such as pressure, temperature, and flow sensors) into digital data for real-time processing by central controllers, integrating advanced signal conditioning and noise reduction technologies to ensure measurement accuracy. Widely applied in petrochemical reactors, thermal power plant boilers, and water treatment systems, it accurately captures subtle changes in process parameters, providing reliable data support for closed-loop control and process optimization. Its modular design supports hot-swapping for maintenance efficiency, while optical isolation between channels prevents cross-interference from strong electrical signals. Fully compatible with ABB’s control platforms, it communicates via PROFINET and Modbus TCP protocols, enabling seamless integration into large-scale automation networks.

3BHE009017R0101

3BHE009017R0101 Technical Specifications

Product Model: XVC724BE101 (Order Code: 3BHE009017R0101)
Product Type: High-precision analog input module
Series Affiliation: ABB Ability™ System 800xA / AC 800M DCS Series
Core Functions: Analog signal acquisition, signal conditioning, noise reduction, real-time data transmission, fault diagnosis
Input Channels: 16 differential channels, individually configurable
Input Signal Types: 4-20mA DC, 0-10V DC, thermocouple (K/J/T type), RTD (PT100/PT1000)
Measurement Accuracy: ±0.02% of full scale (for 4-20mA signals); ±0.1°C (for PT100 temperature measurement)
Signal Sampling Rate: 100 samples per second per channel
Isolation Performance: Channel-to-channel isolation 500Vrms; Module-to-ground isolation 1kVrms
Communication Interface: 2×Ethernet ports; Supports PROFINET, Modbus TCP
Power Supply: 24VDC (redundant input supported); Power consumption ≤8W
Operating Environment: Temperature -20°C to +65°C; Humidity 5-95% (non-condensing); IP20 protection rating (cabinet-mounted)
Mechanical Features: 140mm×110mm×40mm (L×W×H); Weight ~0.5kg; DIN rail mount; LED status indicators per channel
Certifications: CE, UL certified; Compliant with IEC 61131-2, SIL 2 safety standards
