Allen Bradley 1326-CPC1-015 Product Specification
1. Product Overview
The Allen Bradley 1326-CPC1-015 is a high-performance permanent magnet servo motor belonging to Rockwell Automation’s 1326 series. As a core executive component in motion control systems, it converts electrical energy into precise mechanical motion, providing stable torque and speed output for automated equipment. Widely applied in CNC machining centers, robotic arms, packaging machinery, and precision material handling systems, this servo motor ensures high positional accuracy and dynamic response, supporting efficient and high-quality industrial production.
Compliant with international standards including IEC 60034-1 and UL 1004, the 1326-CPC1-015 features a compact permanent magnet design, high power density, and excellent heat dissipation performance. It maintains reliable operation in harsh industrial environments with temperature fluctuations, vibration, and dust, meeting the stringent performance requirements of precision motion control systems.
2. Technical Parameters & Specifications
|
Category
|
Details
|
|
Product Model
|
Allen Bradley 1326-CPC1-015
|
|
Product Type
|
Permanent Magnet Servo Motor (Brushless)
|
|
Rated Power
|
1.5 kW (2.01 HP)
|
|
Rated Voltage
|
400 V AC (3-Phase)
|
|
Rated Current
|
3.8 A (RMS)
|
|
Rated Speed
|
3000 RPM
|
|
Rated Torque
|
4.77 N·m (42.2 lb-in)
|
|
Peak Torque
|
14.3 N·m (126.6 lb-in)
|
|
Encoder Type
|
17-Bit Absolute Encoder
|
|
Motor Length
|
194 mm (7.64 in)
|
|
Environmental Ratings
|
Operating Temp: 0°C–40°C; Protection Class: IP65; Vibration: ≤2.94 m/s²
|
|
Certifications
|
IEC 60034-1; UL 1004; CE; CSA C22.2; RoHS
|
3. Key Features
3.1 High Power Density & Compact Design
Adopting a high-performance permanent magnet rotor design, the motor delivers 1.5 kW rated power with a compact length of only 194 mm. This high power density saves installation space in equipment cabinets, making it suitable for applications with limited spatial constraints such as small CNC machines and collaborative robots.
3.2 Precise Motion Control
Equipped with a 17-bit absolute encoder, the motor achieves high positional resolution (131072 pulses per revolution), ensuring positional accuracy up to ±0.002 mm in CNC machining applications. The brushless design eliminates mechanical wear, reducing maintenance requirements and ensuring consistent motion precision over long service life.
3.3 Excellent Dynamic Performance
With a peak torque of 14.3 N·m (3x rated torque), the motor enables rapid acceleration and deceleration, supporting dynamic load changes in robotic handling and packaging applications. The low rotor inertia design ensures fast response to control signals, reducing motion overshoot and improving production efficiency.
3.4 Robust Environmental Adaptability
The motor features an IP65 protection class, effectively preventing dust and water splashes from entering the internal components. It operates stably in 0°C–40°C environments and resists vibration up to 2.94 m/s², ensuring reliable performance in harsh manufacturing scenarios like automotive parts processing and food packaging plants.
4. Related Allen Bradley Products
-
Allen Bradley 1326-CPC1-030: 3.0 kW servo motor (same series), suitable for high-power motion control applications.
-
Allen Bradley Ultra3000 Servo Drive: Matching servo drive, providing precise speed and torque control for 1326-CPC1-015.
-
Allen Bradley 1394C-SJT22-T-RL: SERCOS III communication module, enabling real-time data exchange between the motor and ControlLogix PLC.
-
Allen Bradley ControlLogix 5580 PLC: Core controller, coordinating the servo motor and associated automation components.
-
Allen Bradley 1756-IF8H Analog Input Module: High-precision AI module, monitoring motor temperature and current signals for predictive maintenance.
