B&R 0GH-AT610 Product Overview
Product Description
The B&R 0GH-AT610 is a high-performance industrial automation module designed for advanced distributed I/O and process control applications. Engineered to deliver precision and reliability in harsh industrial environments, this module acts as a bridge between field devices (sensors, actuators) and higher-level control systems, enabling seamless data acquisition, signal conditioning, and real-time communication. It is ideally suited for applications requiring scalable I/O expansion, multi-protocol compatibility, and ruggedized design.
Product Parameters
- Power Supply:
- Input Voltage: 24V DC ±10% (wide-range compatibility)
- Power Consumption: ≤5W (standby); ≤15W (full operation)
- Communication Interfaces:
- EtherCAT (real-time industrial Ethernet)
- PROFINET (for PLC integration)
- CANopen (for sensor/actuator networks)
- RS-485 (modular expansion via slave modules)
- I/O Capabilities:
- Supports up to 32 digital inputs/outputs (configurable via software)
- 8-channel analog input (0–10V, 4–20mA) with 16-bit resolution
- 4-channel analog output (0–10V, 4–20mA)
- Processing Speed:
- Cycle time: <1ms for I/O updates
- Protocol handling: 100Mbps Ethernet throughput
- Environmental Ratings:
- Operating Temperature: -20°C to +70°C
- Humidity: 5–95% RH (non-condensing)
- Vibration/Shock Resistance: Compliant with IEC 60068-2-6/29
Product Specifications
- Physical Dimensions:
- Width: 53 mm
- Height: 125 mm
- Depth: 100 mm
- Mounting:
- DIN rail (35mm) or panel-mountable
- Connectors:
- Spring-clamp terminals for field wiring (0.14–1.5 mm²)
- M12 Ethernet and CANopen ports
- Certifications:
- CE, UL, CSA, and ATEX (for hazardous environments)
Series Compatibility
The 0GH-AT610 is part of B&R’s X20 modular I/O system, renowned for its flexibility and scalability. This series allows users to mix and match modules (digital, analog, safety, and communication) in a single chassis, reducing inventory costs and simplifying system integration. Key advantages of the X20 series include:
- Hot-swap capability for maintenance without downtime.
- Distributed intelligence for edge computing.
- IP20-rated enclosures for rack-mounted applications.
Key Features
- Multi-Protocol Flexibility:
Supports industry-standard protocols (EtherCAT, PROFINET, CANopen) for seamless integration with PLCs, HMIs, and cloud platforms. - High Precision:
16-bit analog conversion ensures accurate measurement of variables like temperature, pressure, and flow. - Ruggedized Design:
Industrial-grade components withstand EMI/RFI interference, extreme temperatures, and mechanical stress. - Modular Expansion:
Add slave modules (e.g., 0TB6102 terminal blocks 1415) for custom I/O configurations. - Diagnostic Capabilities:
Real-time LED indicators and built-in error logging simplify troubleshooting.
Functions
- Data Acquisition: Collects analog/digital signals from sensors (e.g., proximity switches, pressure transducers).
- Signal Conditioning: Filters noise, amplifies weak signals, and linearizes inputs for control systems.
- Actuator Control: Drives motors, valves, and relays via digital/analog outputs.
- Protocol Translation: Converts fieldbus data to a unified format for centralized monitoring.
Primary Uses
- Process Automation:
Monitors and controls production lines in automotive, food & beverage, and pharmaceutical industries. - Machine Safety:
Integrates with safety and emergency stops via X20 safety modules. - Energy Management:
Optimizes power consumption in smart grids and renewable energy systems.
Application Areas
- Manufacturing:
- Robotics cells for precision assembly.
- Conveyor systems with predictive maintenance.
- Oil & Gas:
- Remote monitoring of pumps and compressors in harsh environments.
- Building Automation:
- HVAC control and energy-efficient lighting systems.
- Packaging:
- High-speed labeling and filling machines.
- Water Treatment:
- Real-time monitoring of pH, flow, and chemical dosing.
Conclusion
The B&R 0GH-AT610 exemplifies B&R’s commitment to future-proof industrial automation. By combining X20 series scalability with advanced I/O capabilities, it delivers a compact, reliable solution for modern manufacturing and process control. While specific details may vary based on configuration, this module is a cornerstone for Industry 4.0 applications requiring high performance and adaptability.
