Brief Introduction to B&R 3CP260.60-1 Compact Control Module
1. Product Description
The B&R 3CP260.60-1 is a compact, cost-effective control module from B&R’s industrial automation product lineup. It is designed for small to medium-sized automation tasks, such as basic machine control, I/O signal management, and simple logic operations. With a space-saving design, it is easy to integrate into tight control cabinets—ideal for applications like packaging machines, small conveyors, or material handling equipment. It focuses on reliability and ease of use, supporting basic control functions without complex programming requirements, making it suitable for both new installations and retrofits of simple automation systems.
2. Technical Specifications
- Power Supply: 24 V DC (18–32 V DC, wide input range for industrial stability)
- Digital I/O: 8 digital inputs (24 V DC) + 4 digital outputs (24 V DC, 0.5 A per channel)
- Analog I/O: 2 analog inputs (0–10 V DC, 12-bit resolution)
- Communication Interface: 1 x EtherCAT port (for fast data exchange with other B&R devices)
- Operating Temperature: 0°C to +55°C (suitable for most industrial environments)
- Dimensions: Compact form factor (approx. 100 mm × 60 mm × 30 mm, panel-mountable)
- Programming Support: Compatible with B&R Automation Studio software (simple ladder logic or function block programming)
3. System Introduction
The 3CP260.60-1 is part of B&R’s “Compact Control” system ecosystem, which focuses on flexible, modular automation for small-scale applications. It works seamlessly with other B&R components—such as small HMIs (e.g., B&R Panel 400) or basic drives—to form a complete small automation solution. It uses the EtherCAT protocol for real-time communication, ensuring fast response between the module and connected devices. The system is designed for simplicity: users can configure the module via B&R Automation Studio with minimal training, and it supports basic diagnostic functions (e.g., input/output status checks) to reduce troubleshooting time. It is widely used in industries like food processing, light manufacturing, and small-scale logistics automation.
4. Recommended Related Models in the Same Series
- B&R 3CP261.60-1: Expanded I/O version—12 digital inputs + 6 digital outputs, plus 2 analog outputs (0–10 V DC) for more complex signal control.
- B&R 3CP262.60-1: Adds basic motion control functions (for 1-axis stepper/servo drives) while keeping the same compact size—ideal for small machines with simple motion needs (e.g., small CNC routers).
- B&R 3CP250.60-1: Entry-level model with fewer I/O (6 digital inputs + 2 digital outputs) and no analog inputs—cost-effective for ultra-simple tasks like on/off control of fans or pumps.
- B&R 3CP270.60-1: Enhanced communication version—adds a second Ethernet port (for TCP/IP) besides EtherCAT, suitable for systems needing connection to upper-level SCADA.
- B&R 3CP280.60-1: Ruggedized version (operating temperature -20°C to +60°C) with IP20 protection—for harsh industrial environments like cold storage or dusty workshops.
- B&R 3CP260.60-2: Updated variant with higher output current (1 A per digital output) to drive larger loads (e.g., small solenoid valves) without external relays.
