Introduction to CCC TMPU-1002
Product Description
The CCC TMPU-1002 is a high-precision temperature measurement and processing unit designed for industrial environments requiring accurate thermal monitoring, such as manufacturing plants, power generation facilities, and chemical processing systems. As a key component in temperature control systems, it specializes in collecting, processing, and transmitting temperature data from various sensors, ensuring real-time and reliable thermal status tracking of critical equipment and processes.
This unit integrates advanced signal conditioning circuits and microprocessing technology, enabling it to interface with multiple types of temperature sensors. Its robust industrial-grade design allows it to operate stably in harsh conditions involving vibrations, electromagnetic interference, and wide temperature fluctuations. With a compact form factor, it can be easily integrated into existing control systems, providing essential temperature data for process optimization, equipment protection, and energy management.
Technical Parameters
- Sensor Compatibility: Supports thermocouples (K, J, T, E, R, S types) and RTDs (Pt100, Pt1000, Cu50); auto-identification of sensor types available.
- Measurement Range:
-
- Thermocouples: -200°C to 1800°C (depending on thermocouple type)
-
- RTDs: -200°C to 850°C
- Measurement Accuracy: ±0.1% of reading + 0.1°C (for RTDs); ±0.2% of reading + 0.5°C (for thermocouples)
- Resolution: 0.1°C
- Sampling Rate: Up to 10 samples per second per channel
- Input Channels: 8 differential input channels
- Output Signals: 4 analog outputs (4-20mA or 0-10V), 8 digital outputs (relay, 5A/250V AC)
- Communication Interfaces: RS485 (Modbus RTU), Ethernet (Modbus TCP/IP optional)
- Power Supply: 24V DC (18-36V DC), power consumption ≤ 15W
- Operating Environment: Temperature -40°C to +70°C; humidity 5-95% RH (non-condensing)
- Protection Ratings: IP20 (enclosure); surge protection: ±2kV (IEC 61000-4-5)
- Dimensions: 140mm × 100mm × 60mm; weight: approx. 350g
Usage Methods
- Installation:
-
- Mount the unit on a 35mm DIN rail in a control cabinet, ensuring a minimum of 10mm clearance around the unit for ventilation.
-
- Avoid direct exposure to extreme temperatures, strong magnetic fields, or corrosive gases. Secure the unit firmly to prevent vibration-induced loosening.
- Wiring:
-
- Connect temperature sensors to the input terminals, following the polarity markings for thermocouples. For RTDs, use 3-wire or 4-wire configurations to minimize lead resistance errors.
-
- Connect analog and digital outputs to the corresponding control or monitoring devices, ensuring proper wire gauge (0.5-1.5mm²) and tight terminal connections.
-
- Wire the power supply, ensuring correct polarity. Use shielded cables for sensor and communication lines, with shields grounded at one end.
- Configuration:
-
- Access the configuration menu via the front-panel buttons or software (using the RS485 or Ethernet interface). Set sensor types, measurement ranges, and filtering parameters for each channel.
-
- Configure output signals (range and type) and communication parameters (baud rate, parity, IP address for Ethernet).
-
- Set alarm thresholds for digital outputs to trigger alerts or control actions based on temperature limits.
- Operation and Maintenance:
-
- Power on the unit and verify that the status LED indicates normal operation. Check sensor readings on the optional display or via connected software.
-
- Perform regular calibration annually using standard temperature sources to maintain accuracy.
-
- Inspect wiring connections quarterly for tightness and signs of corrosion. Clean the unit’s exterior with a dry cloth to remove dust.
System Introduction
The CCC TMPU-1002 functions as a critical temperature data acquisition node within industrial control systems, integrating with three key layers:
- Sensor Layer: Interfaces with thermocouples or RTDs installed on equipment (e.g., motors, furnaces, pipelines) to capture raw temperature signals.
- Processing Layer: Conditions incoming signals (filtering, amplification) and converts them to digital values via high-precision ADCs. The microprocessor processes data, applies linearization, and computes accurate temperature readings.
- Communication and Control Layer: Transmits processed data to SCADA, DCS, or PLC systems via Modbus protocols. Analog outputs provide real-time temperature signals for closed-loop control, while digital outputs trigger alarms or safety actions when thresholds are exceeded.
In a typical application, such as a chemical reactor system, the TMPU-1002 monitors multiple zones of the reactor vessel. It sends temperature data to a PLC, which adjusts heating or cooling systems via the unit’s analog outputs. If temperatures exceed safe limits, digital outputs activate shutdown mechanisms, preventing equipment damage.
Related Models in the Series
- TMPU-1004: 16-channel temperature measurement unit with enhanced processing power, suitable for large-scale systems requiring extensive monitoring.
- TMPU-2002: Explosion-proof version (ATEX/IECEx certified) for hazardous areas, such as oil refineries or gas processing plants.
- TMPU-1002-W: Wireless temperature unit with Wi-Fi/Bluetooth connectivity, ideal for remote or hard-to-reach installations.
- TMPU-3002: Combines temperature measurement with data logging (8GB storage), enabling offline data recording for trend analysis.
- TMPU-1002-L: Low-power version (≤5W) designed for battery-operated or energy-constrained applications.
- TMPU-4002: Advanced model with built-in PID control algorithms, allowing direct temperature regulation without external controllers.
