Introduction to Chloride TSE1111D
Product Description
The Chloride TSE1111D is a high-performance uninterruptible power supply (UPS) designed for critical industrial and commercial applications requiring reliable backup power. As part of Chloride’s TSE series, this model specializes in providing seamless power transition during mains failures, ensuring uninterrupted operation of sensitive equipment such as servers, control systems, medical devices, and industrial automation machinery.
This UPS integrates advanced inverter technology, battery management systems, and intelligent monitoring capabilities to deliver clean, stable power. Its compact design and modular architecture make it suitable for both standalone installations and parallel configurations, offering scalability to meet varying load demands. With robust protection features against power anomalies (e.g., surges, sags, harmonics), the TSE1111D safeguards connected equipment from damage while maintaining operational continuity—critical for minimizing downtime in mission-critical environments.
Technical Parameters
- Power Rating: 10 kVA / 8 kW (continuous output)
- Input Voltage: 230V AC single-phase (187-276V AC wide range)
- Input Frequency: 50/60 Hz ± 5% (auto-sensing)
- Output Voltage: 230V AC single-phase (±1% regulation)
- Output Frequency: 50/60 Hz (synchronized to input or battery mode with ±0.1% stability)
- Waveform: Pure sine wave (THD < 3% at full load)
- Battery System: Internal VRLA (valve-regulated lead-acid) batteries; 12V, 9Ah cells (6 cells in series)
- Backup Time: 10 minutes at 50% load; 5 minutes at 100% load (extendable with external battery packs)
- Efficiency: ≥92% in online mode; ≥96% in eco mode
- Protection Features: Overload (125% for 10 minutes, 150% for 1 minute), short circuit, overvoltage, undervoltage, overtemperature
- Communication Interfaces: RS232, USB, Ethernet (Modbus TCP/IP); optional SNMP card
- Operating Temperature: 0°C to 40°C (battery charging); 0°C to 50°C (discharging)
- Relative Humidity: 20-90% RH (non-condensing)
- Dimensions: 450mm (W) × 600mm (D) × 2U (89mm H) rack-mount or tower configuration
- Weight: 35 kg (including batteries)
- Certifications: IEC 62040-1, CE, UL 1778
Usage Methods
- Installation:
-
- Mount the UPS in a 19-inch rack (using optional rails) or place it in tower mode on a flat, stable surface. Ensure a minimum clearance of 100mm around the unit for ventilation.
-
- Position the UPS away from direct sunlight, heat sources, and areas with high humidity or dust.
-
- Connect the input power cable to a dedicated 16A circuit breaker, using the provided power cord.
- Wiring:
-
- Connect critical loads to the output terminals (C13/C19 outlets) on the front panel, ensuring total load does not exceed 8 kW.
-
- For remote monitoring, connect a PC or network switch to the USB or Ethernet port using shielded cables.
-
- If extending backup time, connect external battery packs to the dedicated battery terminals (follow polarity markings).
- Commissioning:
-
- Power on the UPS and allow batteries to charge for 24 hours before full operation (LED indicator shows “Charging” status).
-
- Configure operating modes (online/eco) via the front-panel LCD or management software (Chloride PowerManager).
-
- Test the backup function by simulating a mains failure (use the “Test” button) to verify seamless transition to battery power.
- Maintenance:
-
- Perform monthly visual inspections: check for loose connections, bulging batteries, or unusual noises.
-
- Monitor battery health via the LCD or software; replace batteries every 3-5 years (or when capacity drops below 80% of rated).
-
- Clean the air vents quarterly with compressed air to prevent dust buildup.
-
- Schedule annual professional maintenance to test inverter performance, calibration, and safety features.
System Introduction
The Chloride TSE1111D operates as a critical power management node in electrical systems, integrating four key functional layers:
- Input Regulation Layer: Conditions incoming mains power, filtering out harmonics and stabilizing voltage/frequency to protect the inverter and batteries.
- Energy Storage Layer: The VRLA battery bank stores electrical energy, ready to discharge within milliseconds when mains power fails.
- Inverter Layer: Converts DC power from batteries to clean AC power (pure sine wave) during outages, ensuring no interruption to connected loads.
- Monitoring & Control Layer: Intelligent electronics monitor system status, trigger alarms for anomalies, and enable remote management via communication interfaces.
In a typical data center application, the TSE1111D provides backup power to server racks. During a mains failure, it switches to battery mode in <2ms, allowing servers to shut down gracefully or continue operating until backup generators activate. The Ethernet interface sends real-time alerts to facility managers, enabling proactive response to power events.
Related Models in the Series
- TSE1122D: 20 kVA / 16 kW single-phase UPS with extended battery options, suitable for larger loads such as medical imaging equipment.
- TSE3111D: 10 kVA / 8 kW three-phase input/single-phase output model, ideal for industrial environments with three-phase mains.
- TSE1111D-LI: Lithium-ion battery variant with 50% weight reduction and 10-year lifespan, offering faster charging and higher cycle count.
- TSE1111D-RM: Rack-mount optimized version with 1U height, designed for space-constrained data centers.
- TSE1111D-NM: Networked model with built-in SNMP and BMS (Battery Management System) for large-scale UPS fleets.
- TSE1105D: 5 kVA / 4 kW compact version, suitable for small offices, retail POS systems, or laboratory equipment.
