Introduction to METSO D201189L
D201189L Product Overview
The METSO D201189L is a high-reliability industrial digital input module specifically engineered for process automation systems, with a focus on mineral processing, bulk material handling, and heavy industrial applications. As a key component in METSO’s remote I/O and control product lineup, it serves as a critical interface for collecting and transmitting digital signals from field devices such as sensors, switches, and limiters to upper-level control systems. The module adopts a rugged industrial-grade design, optimized to withstand harsh operating conditions characterized by vibration, dust, humidity, and extreme temperatures—typical of mining, metallurgical, and cement production sites. It supports seamless integration with METSO’s mill control systems and other mainstream DCS platforms through standard industrial communication protocols.
D201189L Technical Specifications
-
Product Model: D201189L
-
Product Type: Industrial Tension Control Module
-
Core Functions: Precise tension regulation for rolling processes, real-time tension monitoring, signal processing and conversion, system status diagnosis, seamless integration with industrial control systems
-
Power Supply: 220 VAC input; Built-in voltage stabilization and surge protection; Low power consumption design for energy efficiency
-
Product Model: D201189L
-
Product Type: Industrial Digital Input Module
-
Core Functions: High-speed digital signal acquisition, signal filtering and conditioning, data transmission to upper-level control systems, system status monitoring, fault diagnosis and alarm, seamless integration with industrial control networks
-
Power Supply: 24 VDC wide voltage input (18 VDC – 30 VDC); Built-in voltage regulation and surge protection; Power consumption: ≤ 8 VA
-
Input Channels: 16-channel digital input; Supports dry contact and NPN/PNP transistor signal input
-
Input Signal Range: 0-30 VDC; Signal response time: ≤ 1 ms for high-speed data acquisition
-
Isolation Performance: Photoelectric isolation between channels and power supply; Isolation voltage: ≥ 2500 VAC (1 minute); Strong anti-interference capability complying with IEC 61000-6-2/4 EMC standards
-
Communication Protocols: Compatible with PROFINET and Ethernet/IP protocols; Supports seamless integration with METSO MLCP series local control panels and third-party DCS systems
-
Protection Features: Built-in overcurrent, overvoltage and short-circuit protection for each input channel; Reverse polarity protection for power supply; Dust and moisture resistant housing
-
Environmental Ratings: Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection class: IP67 (suitable for on-site installation in harsh environments)
-
Mechanical Dimensions: Compact modular design; Approximate size (L×W×H): 120 mm × 80 mm × 45 mm; Approximate weight: 0.2 kg
-
Installation Options: DIN rail-mounted or panel-mounted installation; Supports hot-swapping for easy maintenance without system shutdown
-
Certifications: CE, UL certified; RoHS compliant; Complies with international industrial control system safety and EMC standards
Recommended METSO Digital I/O & Control Module Models
-
METSO D200533: 8-channel digital I/O module, supporting both input and output functions for flexible signal interaction
-
METSO D201190L: 32-channel high-density digital input module, ideal for large-scale industrial process monitoring systems
-
METSO D201191L: 16-channel digital output module, specialized for driving relays, contactors, and solenoid valves in field systems
-
METSO BIU 8 A413140: 8-channel intelligent input module with signal conditioning, suitable for high-precision sensor data acquisition
-
METSO A413162: Process control module, facilitating integration of I/O systems into complex mineral processing control loops
-
METSO CI854A 3BSE036469R1: PROFIBUS DP communication interface module, enabling reliable data exchange between I/O modules and controllers
-
METSO D201192L: Redundant digital input module, ensuring continuous data acquisition in critical process control applications
-
METSO D201193L: Digital I/O module with integrated diagnostic function, supporting quick fault location and maintenance
-
METSO MLCP-SIE-S: Siemens-based local control panel, integrating D201189L and other I/O modules for mill control systems
-
METSO D201194L: High-temperature resistant digital input module, suitable for high-heat industrial environments such as smelting processes
