Introduction to DALSA CR-GEN0-M6400R3
Product Description
The DALSA CR-GEN0-M6400R3 is a high-performance line scan camera designed for industrial inspection and machine vision applications. Developed by DALSA (a Teledyne company), a leader in imaging solutions, this camera is engineered to capture high-resolution images of moving objects in continuous processes, making it ideal for applications such as web inspection (paper, film, textiles), print quality control, semiconductor wafer inspection, and packaging verification.
Featuring a large-format CCD sensor and advanced signal processing, the CR-GEN0-M6400R3 delivers exceptional image quality with high sensitivity and low noise, ensuring accurate detection of fine defects even at high line rates. Its rugged industrial design includes a compact aluminum housing, making it suitable for integration into space-constrained production lines. The camera supports multiple data interfaces and triggering modes, enabling seamless integration with machine vision systems for real-time inspection and process control.
Technical Parameters
- Sensor Type: 6400-pixel linear CCD (monochrome)
- Pixel Size: 7μm × 7μm
- Optical Format: 1.2 inches
- Resolution: 6400 pixels per line
- Line Rate: Up to 65 kHz (maximum, at full resolution)
- Sensitivity: 18 V/(lx·s) (typical)
- Dynamic Range: 65 dB (typical)
- Signal-to-Noise Ratio: 58 dB (typical)
- Data Interface: Camera Link (Full), with support for 8/10/12-bit pixel depth
- Trigger Modes: Free-run, external hardware trigger, encoder input (for speed synchronization)
- Exposure Control: Programmable via software; electronic shutter
- Lens Mount: C-mount (standard); optional F-mount adapter available
- Power Supply: 12V DC ±5%, power consumption ≤4W
- Operating Temperature: 0°C to +45°C (32°F to +113°F)
- Storage Temperature: -20°C to +60°C (-4°F to +140°F)
- Relative Humidity: 20-80% RH (non-condensing)
- Protection Rating: IP30 (housing)
- Dimensions: 89mm × 54mm × 33mm (L × W × H)
- Weight: Approximately 150g
Usage Methods
- Installation:
-
- Mount the camera using the integrated M4 threaded holes, ensuring alignment with the target surface and proper distance for the chosen lens (use lens calculators to determine working distance).
-
- Secure the lens to the C-mount, adjusting focus and aperture to optimize image sharpness and light intake.
-
- Position the camera such that the line of sight is perpendicular to the direction of object movement (for web inspection) to ensure uniform image sampling.
- Wiring and Connection:
-
- Connect the 12V DC power supply to the dedicated terminal, using a regulated power source to minimize noise.
-
- Connect the Camera Link cable to the frame grabber in the vision system, ensuring proper termination (follow Camera Link specifications for cable length).
-
- For external triggering, connect the trigger signal (TTL level) to the input terminal; for encoder synchronization, wire the encoder signal to the dedicated input.
- Configuration and Setup:
-
- Use Teledyne DALSA’s Sapera LT software to configure camera parameters, including line rate, exposure time, gain, and pixel format.
-
- Calibrate the camera for geometric distortion and lighting variations using a calibration target (e.g., checkerboard pattern) and software tools.
-
- Set up triggering parameters to synchronize image acquisition with object movement (e.g., using encoder input to adjust line rate based on web speed).
- Operation and Maintenance:
-
- Monitor image quality via the vision system software, adjusting lighting or camera settings if artifacts (e.g., noise, motion blur) appear.
-
- Inspect the lens periodically for dust or smudges; clean with a lens tissue and appropriate cleaning fluid if necessary.
-
- Check cable connections quarterly to ensure secure attachment, especially in high-vibration environments.
-
- Avoid exposing the camera to extreme temperatures or direct sunlight, which may degrade performance or damage components.
System Introduction
The DALSA CR-GEN0-M6400R3 operates as a core imaging component in industrial machine vision systems, integrating with three key layers:
- Imaging Layer: The linear CCD sensor captures light reflected from the target object, converting it into electrical signals proportional to light intensity. Each line of pixels corresponds to a cross-sectional “slice” of the moving object.
- Signal Processing Layer: The camera’s onboard electronics amplify and digitize the sensor signals, applying corrections for dark current and non-uniformity to produce high-quality digital images.
- Inspection Layer: The digitized image data is transmitted to a frame grabber or vision processor, which runs inspection algorithms to detect defects, measure dimensions, or verify patterns. Results trigger real-time actions (e.g., rejecting defective parts, adjusting production parameters).
In a paper web inspection system, the CR-GEN0-M6400R3 captures continuous line scans of the moving web at 65 kHz, generating high-resolution images. The vision system analyzes these images to identify defects such as tears, dirt, or thickness variations. If a defect is detected, the system sends a signal to a marking device or rejection mechanism, ensuring only quality products proceed downstream.
Related Models in the Series
- DALSA CR-GEN0-M8192R3: 8192-pixel resolution model, offering higher detail for applications requiring finer defect detection (e.g., semiconductor wafers).
- DALSA CR-GEN0-M4096R3: 4096-pixel variant with a higher maximum line rate (80 kHz), suitable for high-speed production lines (e.g., packaging inspection).
- DALSA CR-GEN0-M6400C3: Color version with a trilinear CCD sensor, designed for applications requiring color analysis (e.g., print quality control, textile color matching).
- DALSA CR-GEN1-M6400R3: Next-generation model with enhanced sensitivity (25 V/(lx·s)) and dynamic range (70 dB), optimized for low-light environments.
- DALSA CR-GEN0-M6400R3-IR: Infrared-sensitive variant, used for inspecting subsurface defects or materials opaque to visible light (e.g., plastic welding inspection).
- DALSA CR-GEN0-M6400R3-HS: High-speed model with a maximum line rate of 100 kHz (at reduced resolution), ideal for ultra-fast processes (e.g., metal strip inspection).
