Introduction to EATON MTL838C
Product Description
The EATON MTL838C is an advanced intrinsic safety barrier designed to protect electrical equipment and operators in hazardous environments where flammable gases, vapors, or dust are present. As part of Eaton’s MTL800 Series, a renowned line of intrinsic safety solutions, this barrier is engineered to limit electrical energy (voltage, current, and power) to levels below those required to ignite explosive atmospheres. It is widely used in industries such as oil and gas, chemical processing, pharmaceutical manufacturing, and mining, where safety in hazardous zones (e.g., Zone 0/1 for gases, Zone 20/21 for dust) is critical.
The “MTL838C” designation highlights its role as a multi-channel barrier, providing isolated protection for multiple signals simultaneously. Unlike single-channel barriers, the MTL838C integrates four independent channels, making it a space-efficient solution for systems requiring multiple sensor inputs or actuator outputs in hazardous areas. Its robust design includes galvanic isolation between channels and from the power supply, preventing ground loops and electromagnetic interference that could compromise safety or signal integrity. The barrier also features diagnostic capabilities to monitor channel status, enhancing system reliability and reducing downtime.
Technical Parameters
- Number of Channels: 4 independent channels (isolated from each other and power supply)
- Intrinsic Safety Ratings:
-
- Ex ia IIC T4 Ga (ATEX/IECEx)
-
- Suitable for Zone 0, 1, 2 (gases) and Zone 20, 21, 22 (dust)
- Input Signal Type: 4-20mA analog (transmitter/sensor side)
- Output Signal Type: 4-20mA analog (safe area/controller side)
- Power Supply: 24V DC (18-30V DC)
- Power Consumption: ≤1.2W per channel; total ≤5W
- Isolation:
-
- Channel-to-channel: ≥1.5kV AC (rms) for 1 minute
-
- Channel-to-ground: ≥2.5kV AC (rms) for 1 minute
-
- Power-to-signal: ≥2.5kV AC (rms) for 1 minute
- Accuracy: ±0.1% of full scale (4-20mA)
- Response Time: ≤1ms (signal bandwidth 0-5kHz)
- Operating Temperature: -20°C to +60°C (-4°F to +140°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Relative Humidity: 5-95% RH (non-condensing)
- Vibration Resistance: 10-500Hz, 10g peak (IEC 60068-2-6)
- Shock Resistance: 30g peak (11ms duration, IEC 60068-2-27)
- Protection Rating: IP20 (DIN rail mounting)
- Dimensions: 105mm × 100mm × 32mm (W × H × D)
- Weight: Approximately 180g
- Certifications: ATEX, IECEx, UL Class I Div 1, CSA, IEC 61131-2
Usage Methods
- Installation:
-
- Mount the barrier on a standard DIN rail in a non-hazardous area (e.g., control room) or in a certified enclosure if installed near hazardous zones.
-
- Ensure a minimum clearance of 30mm above and below the barrier for ventilation, as heat dissipation is critical for stable operation.
-
- Group barriers by hazardous zone classification to simplify wiring and compliance with safety standards.
- Wiring and Connection:
-
- Connect the 24V DC power supply to the barrier’s power terminal, using a fused circuit (500mA) to protect against overcurrent.
-
- Wire the hazardous area side (Ex) to sensors/transmitters in Zone 0/1 using twisted-pair, shielded cable. Ground the cable shield at the barrier end only to avoid ground loops.
-
- Connect the safe area side (Non-Ex) to controllers, PLCs, or HMIs (e.g., EATON XV Series) using shielded cable, with the shield grounded at both ends for noise immunity.
-
- Verify all connections comply with local wiring codes (e.g., NEC 500, IEC 60079-14) and that the total cable capacitance/inductance does not exceed the barrier’s limits (1nF/km capacitance, 50µH/km inductance).
- Configuration and Testing:
-
- No programming is required; the barrier operates passively once powered. However, verify signal integrity using a multimeter or oscilloscope to ensure 4-20mA signals are transmitted accurately.
-
- Perform a insulation resistance test between channels and ground (≥100MΩ at 500V DC) before commissioning to confirm isolation.
-
- Test intrinsic safety parameters (maximum open-circuit voltage, short-circuit current) using a calibrated test set to ensure compliance with Ex ratings.
- Operation and Maintenance:
-
- Monitor the barrier’s status via optional diagnostic modules (e.g., MTL870) to detect faults such as open circuits or overcurrent in hazardous area wiring.
-
- Perform quarterly visual inspections: check for loose connections, signs of corrosion, or damage to the housing.
-
- Avoid hot-swapping connections in hazardous areas; power down the system before modifying wiring to prevent sparking.
-
- Replace the barrier if isolation resistance drops below 100MΩ or if physical damage is detected.
System Introduction
The EATON MTL838C functions as a critical safety barrier in hazardous area systems, integrating three key layers:
- Intrinsic Safety Layer: Limits voltage (≤18V DC), current (≤93mA), and power (≤1.3W) to hazardous area circuits, ensuring no ignition source is present even in fault conditions.
- Isolation Layer: Galvanic isolation between channels and from the power supply prevents energy transfer between hazardous and safe areas, eliminating ground loops and reducing EMI.
- Signal Transmission Layer: Maintains high-fidelity 4-20mA signal transmission, allowing accurate monitoring of process variables (e.g., pressure, temperature, flow) from hazardous areas to safe area controllers.
In an oil refinery application, the MTL838C protects four pressure transmitters in a Zone 1 area. It limits energy to the transmitters, preventing ignition of flammable gases, while transmitting accurate pressure data to a PLC in the safe area. The barrier’s isolation ensures that a fault in one transmitter (e.g., short circuit) does not affect the other three channels, maintaining system redundancy and safety.
Related Models in the Series
- EATON MTL834C: 2-channel variant of the MTL838C, ideal for smaller systems requiring fewer sensors (e.g., standalone tanks).
- EATON MTL831C: Single-channel barrier with enhanced surge protection (10kA), designed for harsh environments with lightning risk (e.g., offshore platforms).
- EATON MTL838IS: 4-channel barrier with integrated surge protection, suitable for areas with high electromagnetic interference (e.g., near motors or VFDs).
- EATON MTL838B: 4-channel barrier with wider temperature range (-40°C to +70°C), used in extreme environments like arctic oil fields or desert refineries.
- EATON MTL848C: 4-channel barrier for digital signals (24V DC), protecting discrete sensors (e.g., limit switches) in hazardous areas.
- EATON MTL858C: 4-channel barrier with HART protocol support, enabling bidirectional communication with smart transmitters for configuration and diagnostics.
