Eaton XV – 303 – 70 – BE0 – A00 – 1C Product Introduction
1. Product Description
The Eaton XV – 303 – 70 – BE0 – A00 – 1C is an advanced Human Machine Interface (HMI) unit within the XV 300 series. It serves as a crucial link between industrial operators and control systems, offering a user – friendly interface for efficient interaction. With its 7 – inch widescreen, it provides a clear and vivid display for presenting real – time process data, system status, and control commands. The multi – touch projected capacitive (PCT) touchscreen technology enables intuitive operation, similar to modern consumer tablets, allowing operators to perform various functions such as parameter adjustment, system monitoring, and control activation with ease.
Powered by a 24V DC power supply with a current draw of 0.6 A, it is designed to operate reliably in industrial settings. The unit runs on the Windows Embedded Compact 7 Pro operating system, which, combined with an 800 MHz processor, ensures smooth and responsive performance. It comes pre – installed with Codesys software, a powerful tool for programmable logic controller (PLC) configuration, making it suitable for both HMI – only applications and those that require integrated PLC functionality.
2. Product Parameters
Parameter
|
Details
|
Power Supply
|
24V DC, 0.6 A
|
Display
|
7 – inch LED widescreen with a resolution of 1024 x 600 pixels, providing a clear and sharp visual output
|
Touchscreen Technology
|
Projected capacitive (PCT) multi – touch, enabling intuitive and accurate touch – based interactions
|
Communication Ports
|
Single Ethernet 10/100 for network connectivity, useful for integrating with industrial networks; RS – 232 and RS – 485 serial interfaces for connecting to other serial – enabled devices; CAN (Controller Area Network) for reliable communication in industrial automation systems; USB host and USB device ports for peripheral connections
|
Memory
|
512 MB DRAM for efficient data processing and operation; 256000000 MB (as per one source, though another mentions 1 GB internal memory which might need verification) for storing data and applications; 120 kb retain memory for PLC – related data
|
Brightness
|
400 cd/sq – m, ensuring visibility even in well – lit industrial environments
|
Software
|
Codesys software for PLC configuration, allowing users to program and customize control logic
|
3. Product Specifications
- Physical Dimensions: The unit has dimensions of 11.023 inches in length, 6.692 inches in width, and 4.25 inches in depth. Its compact size makes it suitable for installation in various industrial control cabinets and panels.
- Mounting Method: Flush mounting is available, which gives it a sleek and integrated look when installed in control consoles. Additionally, for the 7 – inch and 10.1 – inch models with rear mounting, control console mounting can create a flat surface for a more ergonomic and space – saving installation.
- Enclosure Material: Made of plastic, which offers a balance between durability and lightweight design. The enclosure is designed to protect the internal components from dust, minor impacts, and some environmental factors.
- Operating Temperature Range: Operates within a temperature range of 0 to 50 degrees Celsius, making it suitable for a wide range of industrial applications where the ambient temperature is within this limit.
- Certifications: Complies with EN 61000 – 6 – 4 standards, which indicates its ability to withstand electromagnetic interference and meet certain safety and performance requirements in industrial environments.
4. Series
The XV – 303 – 70 – BE0 – A00 – 1C belongs to the XV 300 series of HMIs by Eaton. This series is designed to enhance industrial automation by providing contemporary control interfaces and command methods. The XV 300 series products are known for their high system performance, thanks to powerful graphic processors that enable fast screen changes and the integration of multimedia elements. They are versatile, being equally suitable for use as simple HMI operator panels or as HMI – PLC units with integrated PLC functionality, catering to different levels of industrial control requirements.
5. Features
- Sleek and Intuitive Design: The tablet – like design with PCT multi – touch technology offers an intuitive user experience. The high – resolution widescreen display, available in different sizes (in this case, 7 inches), can also be set up in portrait mode, providing flexibility in how information is presented.
- Powerful Processing: An 800 MHz ARM Cortex – A9 processor with a high – performance graphics processing unit ensures smooth operation, even when running complex HMI applications with multiple graphical elements and real – time data updates.
- Memory Expansion: An SD card slot is provided for memory extension. This allows for the storage of additional data, such as historical process data, or for system operation from removable memory. It also simplifies the installation of system updates.
- Multiple Communication Interfaces: The comprehensive set of communication interfaces, including Ethernet, serial ports, CAN, and USB, enables seamless integration with a wide range of industrial devices and systems. This makes it easier to connect to PLCs, sensors, actuators, and other components in an industrial network.
- Durable Construction: The heavy – duty, easy – to – clean front with toughened and anti – reflective glass is designed to withstand the rigors of industrial use. It can resist scratches, smudges, and minor impacts, ensuring long – term usability in harsh industrial environments.
6. Function
The primary function of the XV – 303 – 70 – BE0 – A00 – 1C is to provide a user – friendly interface for industrial operators to interact with control systems. It can display real – time process variables such as temperature, pressure, and flow rate in industrial processes. Operators can use the touchscreen to adjust control parameters, start or stop processes, and view system alarms and status information. When used as an HMI – PLC unit, it can also execute control logic programmed using Codesys software, making decisions based on input data from sensors and sending control signals to actuators.
7. Use
In industrial settings, the XV – 303 – 70 – BE0 – A00 – 1C is used in various ways. In manufacturing plants, it can be used to monitor and control production lines. Operators can use it to adjust the speed of conveyor belts, control the operation of robotic arms, and monitor the quality of products being produced. In power generation facilities, it can be used to monitor the status of generators, turbines, and other equipment. Operators can use it to adjust the power output, monitor for any faults, and perform maintenance tasks. In water treatment plants, it can be used to control the water treatment process, adjusting the dosage of chemicals, monitoring water quality parameters, and controlling the operation of pumps and valves.
8. Application Fields
- Manufacturing Industry: Applied in automotive manufacturing plants to control the assembly line operations, including the movement of parts, the operation of robotic welding and painting equipment, and the quality inspection process. In food and beverage manufacturing, it can be used to control the filling, packaging, and quality control processes.
- Power Generation: Used in thermal power plants to monitor and control the boiler, turbine, and generator operations. In renewable energy plants such as wind farms and solar power plants, it can be used to monitor the performance of wind turbines and solar panels, and to control the power conversion and distribution systems.
- Water and Wastewater Treatment: Employed in water treatment plants to control the entire water treatment process, from raw water intake to treated water distribution. In wastewater treatment plants, it can be used to monitor and control the sewage treatment process, including the activation of sludge treatment, the operation of pumps, and the treatment of effluent.
- Oil and Gas Industry: Utilized in oil refineries to control the refining process, including the distillation, cracking, and blending operations. In gas processing plants, it can be used to monitor and control the gas compression, purification, and storage processes.
