Introduction to ELAU SM070-60-010-P0-45-S1-B0
Product Description
The ELAU SM070-60-010-P0-45-S1-B0 is a high-performance synchronous servo motor designed for precision motion control in industrial automation applications. As part of Schneider Electric’s ELAU range (now integrated into the Lexium Motion portfolio), this motor is engineered to work seamlessly with ELAU servo drives (such as the C200 and C400 series), delivering exceptional dynamic response and positioning accuracy. It is ideally suited for applications including packaging machinery, textile equipment, small robotic systems, and precision material handling—where reliable, high-torque performance in a compact form factor is critical.
The model designation “SM070-60-010-P0-45-S1-B0” breaks down its key specifications: “SM070” indicates a 70mm frame size, “60” denotes a 6000 RPM maximum speed, “010” specifies a 1.0 Nm continuous torque rating, and subsequent codes define feedback type, shaft configuration, and mounting options. This motor features a permanent magnet design that ensures high efficiency and low heat generation, even during continuous operation. Its robust construction includes a stainless steel shaft, reinforced bearings, and class F insulation, making it suitable for harsh industrial environments with dust, vibration, and temperature variations.
Technical Parameters
- Frame Size: 70mm (flange diameter)
- Continuous Torque: 1.0 Nm
- Peak Torque: 3.0 Nm (for 10 seconds)
- Maximum Speed: 6000 RPM
- Rated Voltage: 200V AC (compatible with ELAU C200 drives)
- Rated Current: 5.5A (continuous); 16.5A (peak)
- Power Rating: 0.63 kW (continuous)
- Feedback Device: 1024-line incremental encoder (TTL, 5V) with sin/cos commutation signals
- Number of Poles: 4 poles
- Stator Resistance: 1.8 Ω (phase-to-phase)
- Stator Inductance: 6.5 mH (phase-to-phase)
- Moment of Inertia: 0.0008 kg·m²
- Weight: 3.2 kg
- Shaft Diameter: 10mm (with keyway)
- Mounting: Flange mount (ISO 9409-1, 70mm bolt circle)
- Insulation Class: F (temperature rating up to 155°C)
- Protection Rating: IP65 (shaft seal and connector); IP54 (motor body)
- Operating Temperature: -20°C to +40°C (ambient); up to +100°C (motor surface)
- Storage Temperature: -40°C to +80°C
- Vibration Resistance: 10-500Hz, 10g peak (IEC 60068-2-6)
- Shock Resistance: 30g peak (11ms duration, IEC 60068-2-27)
- Certifications: CE, UL 1004, IEC 60034, RoHS
Usage Methods
- Installation:
-
- Mount the motor to the machine frame using M5 bolts (torque: 8 Nm), ensuring the flange is properly aligned to prevent shaft misalignment.
-
- Use a flexible coupling to connect the motor shaft to the load, limiting misalignment to ≤0.1mm axial and ≤0.05mm radial for optimal bearing life.
-
- Ensure the mounting surface is flat (≤0.1mm/100mm) to avoid distortion of the motor housing during installation.
-
- Position the motor away from direct heat sources (e.g., heaters, furnaces) to maintain ambient temperature within -20°C to +40°C.
- Wiring and Connection:
-
- Connect the motor windings (U, V, W) to the servo drive using twisted-pair, shielded cable (min. 0.75mm² cross-section), ensuring correct phase sequence to avoid reverse rotation.
-
- Connect the encoder cable to the drive’s feedback port, using the manufacturer-supplied shielded cable to minimize electromagnetic interference.
-
- Ground the motor frame to the machine chassis using a dedicated ground terminal for electrical safety and noise reduction.
-
- Secure all connectors with locking clips to prevent accidental disconnection in high-vibration environments.
- Commissioning and Calibration:
-
- Pair the motor with a compatible ELAU servo drive (e.g., C200/10/1/1/1/00) and use Schneider Electric’s SoMove software to load the motor’s parameter set.
-
- Perform a drive-to-motor identification procedure to auto-tune the control loop gains, optimizing performance for the connected load.
-
- Test motor rotation in jog mode at low speed to verify correct direction and feedback functionality before full-speed operation.
-
- Calibrate the encoder zero position if precise absolute positioning is required, using the drive’s software tools.
- Operation and Maintenance:
-
- Monitor motor temperature during operation; surface temperature should not exceed 100°C to prevent insulation degradation.
-
- Check for unusual noise or vibration, which may indicate bearing wear or misalignment—address immediately to avoid damage.
-
- Inspect the shaft seal annually for oil leakage (if equipped) and replace if signs of wear are detected.
-
- Clean the motor exterior with a dry cloth; avoid using water or chemical cleaners on the housing.
-
- Lubricate bearings every 10,000 operating hours (or as specified in the maintenance manual) to extend service life.
System Introduction
The ELAU SM070-60-010-P0-45-S1-B0 functions as the mechanical output component in precision motion control systems, working in tandem with a servo drive and motion controller to deliver accurate, dynamic motion. Its integration into the system involves three key interactions:
- Power Conversion: The servo drive converts AC input power to variable-frequency AC to drive the motor’s stator windings, generating a rotating magnetic field that interacts with the permanent magnet rotor to produce torque.
- Feedback Loop: The incremental encoder provides real-time position and velocity data to the drive, enabling closed-loop control that adjusts current to maintain precise speed or position setpoints.
- Mechanical Transmission: The motor’s torque is transmitted through the shaft to the load (e.g., a conveyor, pulley, or robotic arm), with the coupling ensuring efficient power transfer while isolating the motor from load-induced vibrations.
In a small packaging machine, this motor drives a film-feeding roller, working with a C200 servo drive and PMC motion controller. The controller sends position setpoints to the drive, which adjusts the motor’s speed to feed film at a precise rate synchronized with sealing and cutting mechanisms. The encoder provides feedback to correct for any speed variations, ensuring film length accuracy of ±0.5mm—critical for consistent package sealing. The motor’s 1.0 Nm continuous torque ensures reliable operation even during peak load conditions (e.g., thick film or cold environments).
Related Models in the Series
- ELAU SM070-60-005-P0-45-S1-B0: 0.5 Nm continuous torque variant, ideal for lighter loads such as small conveyor belts or labeling heads.
- ELAU SM070-60-020-P0-45-S1-B0: 2.0 Nm continuous torque model, suitable for applications requiring higher torque, such as small robotic arms or material lifts.
- ELAU SM090-60-030-P0-45-S1-B0: 90mm frame size motor with 3.0 Nm torque, designed for larger machinery like medium-duty packaging lines.
- ELAU SM070-30-010-P0-45-S1-B0: 3000 RPM maximum speed version, optimized for applications where lower speed and higher torque are needed (e.g., precision winding machines).
- ELAU SM070-60-010-A0-45-S1-B0: Equipped with an absolute encoder (SSI) for applications requiring position memory after power loss (e.g., robotic positioning systems).
- ELAU SM070-60-010-P0-45-S1-B1: IP67-rated variant with enhanced sealing, suitable for washdown environments such as food processing or pharmaceutical equipment.
