Emerson 1C31113G01 is a high-speed analog input module specifically designed for the Ovation distributed control system. It supports multiple voltage input ranges such as ±20mV, ±100mV and ±250mV, comes with 13 – 14 – bit resolution, and achieves reliable signal collection with a sampling rate of 50 – 60 samples per second. Equipped with Ethernet, RS – 485 and USB communication interfaces, it is compatible with protocols like Modbus and Ethernet/IP, enabling seamless data exchange with upper – level control systems. Featuring a hot – swappable modular design, it simplifies on – site installation and maintenance. With resistance to electromagnetic interference and stable operation in environments ranging from 0°C to 70°C (5%-95% non – condensing humidity), it is widely applied in power generation, petrochemicals and metallurgy industries for precise acquisition of signals from temperature and pressure sensors to support critical industrial process monitoring.
Emerson’s Ovation system is a distributed control system (DCS) specifically designed for the power generation and water/wastewater treatment industries. As a reliable innovation platform, it provides comprehensive control capabilities and powerful system integration. The main components of Ovation system include:
1. Host: It is the core of the entire system, responsible for data processing, storage, and forwarding, as well as controlling the execution of logic.
2. Screen: It is an interface for users to interact with the system, used to display real-time data, alarm information, trend charts, etc., and allows users to set parameters and control operations.
3. Sound system: Provides sound alarm function. When the system detects abnormal situations or faults, it will emit sound prompts through the sound system, so that operators can respond in a timely manner.
4. Projector: In some applications, it may be used for large screen display, allowing multiple people to simultaneously view system status and operation information.
5. Touch devices: such as touch screens, provide an intuitive operating interface, allowing users to easily perform various controls and settings.
6. Control system: including control logic, algorithms, and strategies, used to achieve precise control of industrial processes.
7. I/O modules and interfaces: used for connecting and exchanging data with external devices such as sensors, actuators, etc. These modules can convert signals from external devices into digital signals that the system can recognize, or convert control signals from the system into instructions that external devices can execute.
8. Communication and network equipment: Ensure data communication and information sharing between internal components of the system and between the system and other external systems.
9. Software and firmware: including operating systems, control software, databases, etc., to provide necessary support and guarantees for the normal operation of the system.
