Emerson KJ4001X1-BE1 (part number 12P0818X072) is an 8-wide I/O carrier specially developed for the DeltaV distributed control system. It comes with 8 configurable digital I/O channels and supports multiple signal types, capable of connecting up to eight modules like analog and digital I/O modules to realize stable access and output of on-site sensor and actuator signals. It operates on 24V DC, adopts Modbus TCP/IP and Ethernet/IP protocols for smooth system integration, and is equipped with shielding design to reduce electromagnetic interference and built-in fault monitoring for easy troubleshooting. With an IP20 rating and operating stably in environments ranging from -40°C to 85°C and 5%-95% non-condensing humidity, it has obtained ATEX, IECEx and other certifications for hazardous areas. Weighing 0.9kg with a compact size of 100mm×50mm×25mm, it is widely applied in power plants, petrochemicals and pharmaceuticals to enhance the scalability and reliability of industrial control systems.
Emerson’s Ovation system is a distributed control system (DCS) specifically designed for the power generation and water/wastewater treatment industries. As a reliable innovation platform, it provides comprehensive control capabilities and powerful system integration. The main components of Ovation system include:
1. Host: It is the core of the entire system, responsible for data processing, storage, and forwarding, as well as controlling the execution of logic.
2. Screen: It is an interface for users to interact with the system, used to display real-time data, alarm information, trend charts, etc., and allows users to set parameters and control operations.
3. Sound system: Provides sound alarm function. When the system detects abnormal situations or faults, it will emit sound prompts through the sound system, so that operators can respond in a timely manner.
4. Projector: In some applications, it may be used for large screen display, allowing multiple people to simultaneously view system status and operation information.
5. Touch devices: such as touch screens, provide an intuitive operating interface, allowing users to easily perform various controls and settings.
6. Control system: including control logic, algorithms, and strategies, used to achieve precise control of industrial processes.
7. I/O modules and interfaces: used for connecting and exchanging data with external devices such as sensors, actuators, etc. These modules can convert signals from external devices into digital signals that the system can recognize, or convert control signals from the system into instructions that external devices can execute.
8. Communication and network equipment: Ensure data communication and information sharing between internal components of the system and between the system and other external systems.
9. Software and firmware: including operating systems, control software, databases, etc., to provide necessary support and guarantees for the normal operation of the system.
