Introduction to UniOP eTOP310U101
The UniOP eTOP310U101 is a compact and rugged industrial Human-Machine Interface (HMI), recognized as the “visual interaction bridge” for small to medium-sized automated control systems. As a key product in UniOP’s eTOP series, it integrates a high-brightness touchscreen display, multi-protocol communication capabilities, and simplified programming functions, specializing in enabling operators to monitor real-time process parameters, input control commands, and view fault alerts intuitively. This HMI is widely applied in industries such as manufacturing automation, food & beverage processing, and building energy management—for example, serving as the operation terminal for PLC-controlled conveyor lines, displaying temperature and pressure data of pasteurization equipment, or managing the running status of air conditioning and ventilation systems in industrial workshops. Its industrial-grade design features a scratch-resistant tempered glass panel and IP65 front protection rating, effectively resisting dust, water splashes, and accidental impacts on the production site.
eTOP310U101 Key Technical Specifications
-
Device Type: Compact industrial Human-Machine Interface (HMI)
-
Core Functions: Real-time data visualization, touch control input, fault alarm display, process parameter recording
-
Display Specifications: 3.5-inch TFT LCD; resolution 320×240 pixels; brightness 350 cd/m²; contrast ratio 500:1; viewing angle ≥140° (horizontal/vertical)
-
Touchscreen: 4-wire resistive touch; 1 million touch life; response time ≤10ms
-
Input/Output Interface: 1×RS485; 1×RS232; 1×USB 2.0 (for programming/ data transfer); 1×24V DC power input
-
Communication Protocols: Supports Modbus RTU, Siemens PPI, Allen-Bradley DF1, Mitsubishi FX, IEC 60870-5-101
-
Power Supply: 24V DC (nominal); input range 18-30V DC; typical power consumption ≤8W; no-load current ≤100mA
-
Operating Environment: Temperature -10°C to +60°C; humidity 10-90% (non-condensing); vibration resistance 10-500Hz (1g)
-
Physical Specifications: 120mm×80mm×35mm (W×H×D); weight ~0.3kg; panel mounting (cutout size 110mm×70mm)
-
Protection Features: Front panel IP65; overvoltage protection; reverse polarity protection; ESD protection (±8kV contact discharge)
-
Software Compatibility: Supports UniOP HMI Configurator V4.0+; compatible with Windows 7/10/11 for project development
-
Certifications: CE, UL 508 compliant; RoHS certified; meets IEC 61131-2 industrial control standards
Recommended UniOP Related Models
-
UniOP eTOP310U102: Enhanced version of eTOP310U101 with Ethernet port, supports remote monitoring via TCP/IP
-
UniOP eTOP515U201: 5.7-inch HMI with 640×480 resolution, ideal for complex process visualization requiring larger display
-
UniOP eTOP205U001: 2.5-inch ultra-compact HMI, cost-effective option for small equipment like single-axis robots
-
UniOP eTOP720U301: 7-inch widescreen HMI with capacitive touch, suitable for food processing lines with frequent operation
-
UniOP eTOP310U103: Marine-grade variant of eTOP310U101, enhanced corrosion resistance for shipboard equipment control
-
UniOP eTOP412U101: 4.3-inch HMI with analog input interface, directly connects to temperature sensors without PLC
-
UniOP eTOP618U401: 10.1-inch large-screen HMI, supports multi-touch for centralized control of production lines
-
UniOP eTOP310U104: High-temperature variant (operating temp up to 70°C), suitable for steel mill and foundry applications
-
UniOP eTOP510U202: 5-inch HMI with built-in data logger, records 10,000+ process data points for quality analysis
-
UniOP eTOP210U002: 2-inch basic HMI with LED display, specialized for simple on/off control of pumps and valves
-
UniOP eTOP725U302: 7-inch HMI with wireless Wi-Fi module, enables mobile operation of remote equipment
-
UniOP eTOP310U105: Explosion-proof variant (ATEX Zone 2), suitable for petrochemical and pharmaceutical hazardous areas
-
UniOP eTOP520U203: 5.7-inch HMI with redundant communication ports, ensures stable connection in critical systems
-
UniOP eTOP930U501: 12.1-inch industrial panel PC integrated with HMI, supports complex SCADA functions
-
UniOP eTOP415U102: 4.3-inch HMI with waterproof front panel (IP67), ideal for washdown environments in dairy plants View more …..
