Brief Introduction to HIMA F3 DIO 20/8 02 Safety I/O Module
In safety-critical industrial processes—such as chemical reactor control, oil and gas pipeline monitoring, and pharmaceutical production lines—safety I/O modules are the “nerve endings” that connect field equipment and safety controllers. The HIMA F3 DIO 20/8 02 is a high-integrity digital I/O module designed for these scenarios, ensuring accurate signal transmission and reliable execution of safety actions to prevent hazardous incidents.
1. Product Overview
The HIMA F3 DIO 20/8 02 is a safety-grade digital input/output module, belonging to HIMA’s renowned F3 series which is widely recognized in the safety instrumented system (SIS) field. It holds SIL 3 certification (per IEC 61508/61511), making it suitable for medium-to-high risk industrial processes like petrochemicals, power generation, and marine engineering.
Its core value lies in the “safety-first + high integration” design. The module integrates 20 digital input channels and 8 digital output channels, realizing both on-site signal collection and control command execution in one unit—this reduces the number of modules in the cabinet and simplifies wiring. Unlike ordinary industrial I/O modules, it adopts dual-channel isolation and fault self-diagnosis functions. For example, in a chemical plant’s emergency shutdown system, if a sensor signal is abnormal, the F3 DIO 20/8 02 can quickly identify the fault and switch to the standby signal source, ensuring the safety controller receives accurate data.
The module also features user-friendly design: its front panel has clear LED indicators for each channel’s working status (on/off, fault), allowing maintenance personnel to locate problems at a glance. It supports hot swapping, meaning the module can be replaced without shutting down the entire SIS, minimizing production downtime caused by maintenance.
2. Technical Specifications
The F3DIO20/802 balances strict safety requirements and practical industrial applicability, with specifications tailored to safety-critical scenarios:
-
Safety Integrity Level: SIL 3 (complies with IEC 61508 Edition 2, IEC 61511)—meets the highest safety standards for medium-to-high risk processes
-
Module Type: Digital input/output (I/O) combined module
-
Channel Configuration: 20 digital input channels, 8 digital output channels
-
Input Signal: DC 24V, dry contact/PNP/NPN input—compatible with mainstream on-site sensors
-
Output Signal: DC 24V, semiconductor output (each channel 0.5A) or relay output (optional)—supports small actuators
-
Communication Interface: HIMA F-Bus—high-speed safety bus, compatible with HIMA F3 controllers
-
Power Supply: DC 24V (18–32V DC), with reverse polarity protection
-
Operating Temperature: -20°C to +60°C—adapts to most industrial workshop environments
-
Isolation Performance: Channel-to-channel isolation ≥ 500Vrms, signal-to-bus isolation ≥ 2.5kVrms—strong anti-interference
-
Dimensions: 100mm × 140mm × 210mm (rail-mounted)—fits standard DIN 35mm rails
-
Protection Level: IP20 (module body)—suitable for cabinet installation
-
Response Time: Input response ≤ 1ms, output response ≤ 2ms—timely for safety events
3. System Integration & Application
The F3DIO20/802 is a key component of HIMA’s “F3 Safety Instrumented System”, which consists of HIMA F3 controllers (such as F3330, F3340), F3 series I/O modules, HIMA Safety Manager software, and HMI operation interfaces. This system is designed to be fully redundant, ensuring that a single module or component failure will not affect the overall safety function.
Take the safety control system of a petrochemical plant’s catalytic cracking unit as an example to understand its working process:
-
On-site sensors (pressure transmitters, temperature switches, gas detectors) collect parameters such as reactor pressure, temperature, and flammable gas concentration, and send digital signals to the 20 input channels of the F3 DIO 20/8 02.
-
The module performs signal isolation and fault detection, then transmits the processed data to the HIMA F3340 safety controller via the F-Bus.
-
The controller compares the real-time data with the preset safety thresholds. If the reactor pressure exceeds the limit, it immediately sends an emergency shutdown command to the F3 DIO 20/8 02.
-
The module’s output channels drive the emergency shut-off valve to close and cut off the feed pump, while sending a fault alarm signal to the central control room’s HMI.
-
During the process, the module conducts self-diagnosis every 100ms. If an input channel fails, it automatically marks the faulty channel and switches to the standby sensor signal, ensuring the system continues to operate safely.
This system is favored by global energy and chemical enterprises because of its strict safety compliance, stable performance, and easy maintenance. The F3 DIO 20/8 02 also supports online configuration—engineers can modify channel parameters through the Safety Manager software without disconnecting the module, improving debugging efficiency.
4. Recommended HIMA Related Models
HIMA’s F3 series has a complete product matrix to meet different channel requirements, application scenarios, and safety levels. Here are the most practical related models for various needs:
-
HIMA F3 DIO 32/16 02: Enhanced combined module—32 input + 16 output channels, suitable for large-scale I/O nodes (e.g., chemical plant central control rooms)
-
HIMA F3 DI 32 02: Pure digital input module—32 channels, for scenarios requiring massive signal collection (e.g., power plant boiler auxiliary equipment monitoring)
-
HIMA F3 DO 16 02: Pure digital output module—16 channels, for scenarios with multiple control commands (e.g., automated warehouse conveyor system)
-
HIMA F3 AIO 8/4 02: Analog I/O combined module—8 analog input + 4 analog output channels, for continuous parameter control (e.g., water treatment plant dosing system)
-
HIMA F3 AI 16 02: Analog input module—16 channels (4–20mA), for collecting temperature, pressure, flow signals (e.g., oil pipeline monitoring)
-
HIMA F3 AO 8 02: Analog output module—8 channels (4–20mA), for controlling regulating valves and frequency converters (e.g., refinery distillation unit)
-
HIMA F3 DIO 20/8 02 EX: Explosion-proof variant (ATEX/IECEx Zone 2 certified)—for hazardous areas (e.g., offshore oil drilling platforms)
-
HIMA F3 DI 16 02 HI: High-temperature resistant module—operating temperature up to +85°C, for high-temperature scenarios (e.g., steel mill blast furnace control)
-
HIMA F3 DO 8 02 HD: High-current output module—each channel 2A, for driving large actuators (e.g., large gate valves in water conservancy projects)
-
HIMA F3 COM 1 02: Communication module—supports Modbus TCP/Profinet, for connecting with non-HIMA systems (e.g., intelligent factory MES systems)
-
HIMA F3330 Controller: Matching safety controller—small and compact, suitable for small-scale SIS (e.g., small chemical workshops)
-
HIMA F3340 Controller: High-end safety controller—supports multiple I/O modules, for large-scale SIS (e.g., petrochemical complex) View more.
