GE 151X1235BC01SA01 programmable logic controller (PLC) module
GE 151X1235BC01SA01 – Product Overview
The GE 151X1235BC01SA01 is a programmable logic controller (PLC) module from GE’s VersaMax Series, designed for industrial automation and control systems. This high-performance I/O module provides flexible signal interfacing for sensors/actuators and integrates seamlessly with VersaMax racks. Its rugged design ensures reliable operation in harsh industrial environments.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer Part Number
|
151X1235BC01SA01
|
|
Product Type
|
VersaMax I/O Module (Analog/Digital Interface)
|
|
Series/Platform
|
GE VersaMax PLC System
|
|
Module Width
|
30mm (Single-slot)
|
|
Input/Output Channels
|
16 points (Configurable as DI/DO/AI/AO)
|
|
Voltage Rating
|
24VDC (Field Power)
|
|
Signal Ranges
|
±10V, 0-20mA, 4-20mA (Analog); 24VDC Sink/Source (Digital)
|
|
Isolation
|
1500V AC channel-to-bus
|
|
Resolution
|
12-bit (Analog)
|
|
Backplane Current
|
80mA @ 5VDC
|
|
Operating Temperature
|
-20°C to +70°C
|
|
Communication Protocol
|
VersaMax Backplane (Profibus-DP optional via adapter)
|
|
LED Indicators
|
Per-channel status + Module health
|
|
Certification
|
UL 508, CE, cULus, RoHS
|
|
Housing Material
|
Polycarbonate (IP20 protection)
|
Series & Family
- Series: GE VersaMax I/O
- Generation: VersaMax Micro/Nano Series
- Compatible Controllers: IC200CPUE05, IC200CPU100, VersaMax Pro
- Related Modules: 151X1235BG01, 151X1235BD01 (variants)
Key Features
- Universal Channel Config: Software-configurable per channel as DI/DO/AI/AO
- Hot-Swappable: Field-replaceable without system shutdown
- High-Density: 16 points in 30mm space
- Diagnostic LEDS: Per-channel status indication
- Auto-Calibration: Self-calibrating analog inputs
- Surge Immunity: 4kV ESD protection per IEC 61000-4-2
- Fast Update Rate: 1ms digital I/O response time
Function & Role
- Signal Conversion: Interfaces between field devices and PLC CPU
- Data Acquisition: Samples analog signals at 1kHz
- Isolation Barrier: Protects CPU from field-side transients
- Power Distribution: Supplies 24VDC to field devices
- Diagnostic Hub: Reports open wire/short circuit faults
Primary Applications
- Discrete Control: Relay outputs for motors/valves
- Analog Monitoring: Temperature/pressure transmitters
- Process Automation: PID control loops
- Machine Safety: Emergency stop circuits
- Batch Processing: Level/flow measurement
Application Fields
- Manufacturing: Assembly line control, robotic cells
- Energy: Wind turbine pitch control, substation monitoring
- Water Treatment: Pump station control, chemical dosing
- Oil & Gas: Wellhead monitoring, pipeline SCADA
- Building Automation: HVAC control, lighting systems
