1. Product Description
The GE D20ME (P/N 526-2005-216943) is an Ethernet communication interface module for the GE D20 Programmable Logic Controller (PLC) system. It enables TCP/IP connectivity between the PLC backbone and supervisory systems (SCADA/HMI) through a 10BASE-T Ethernet port.
Key Role: Bridges D20 PLC racks to plant networks for real-time data exchange.
2. Specifications & Parameters
|
Parameter
|
Specification
|
|---|---|
|
Model
|
D20ME / 526-2005-216943
|
|
Interface
|
10BASE-T Ethernet (RJ45)
|
|
Protocol
|
GE SRTP (Secure Real-Time Protocol)
Modbus TCP (Limited support via gateway) |
|
Data Rate
|
10 Mbps
|
|
Backplane Port
|
D20 Parallel Bus (5V DC)
|
|
Isolation
|
1,500V AC (network-to-backplane)
|
|
LED Indicators
|
Power, Network Activity, Error
|
|
Power Consumption
|
500 mA @ 5V DC (backplane)
|
|
Operating Temp.
|
-40°C to +70°C (Industrial Grade)
|
|
Certifications
|
UL 508, cUL, CE, FCC Part 15
|
3. Series & Compatibility
- Series: GE D20 PLC I/O & Communication Modules
- Compatible CPUs:
- D20 ECPU (e.g., D20 500-1061)
- D20 MICRO (e.g., D20 500-1001)
- Backplane Support:
- D20 Baseplates (e.g., 526-1001-xxx) with ≥1 free slot
- Related Modules:
- Serial Comm: D20MC (Modbus)
- Genius Comm: D20GM
- Remote I/O: D20RI
4. Key Features
- Legacy Network Integration: Connects D20 PLCs to early Ethernet-based SCADA systems.
- Rugged Design: Operates in extreme temperatures (-40°C to +70°C).
- SRTP Protocol: GE’s proprietary real-time protocol for deterministic data transfer.
- Dual-Port Memory: Buffered data exchange between Ethernet and D20 backplane.
- Diagnostic LEDs: Quick status monitoring (power/link/error).
5. Functionality
- Enables remote PLC programming (via LogicMaster 90-30/70 software).
- Facilitates real-time data exchange with HMIs (CIMPLICITY, iFIX).
- Supports alarm reporting and historical logging to central servers.
6. Applications
|
Application
|
Use Case
|
|---|---|
|
SCADA Integration
|
Water treatment plant remote monitoring
|
|
Data Logging
|
Recording process variables (pressure/temperature) in oil refineries
|
|
HMI Connectivity
|
Operator interface for manufacturing equipment
|
|
Remote Diagnostics
|
Troubleshooting PLC logic from control rooms
|
|
Legacy System Modernization
|
Bridging D20 PLCs to modern Ethernet networks
|
7. Target Industries
- Power Generation: Turbine control, substation automation
- Water/Wastewater: Pump station control, reservoir management
- Oil & Gas: Wellhead monitoring, pipeline SCADA
- Manufacturing: Batch process control, conveyor synchronization
- Transportation: Tunnel ventilation control, signal systems
