GE Electric | 531X309SPCAJG1 | PACSystems™ RX3i Redundant CPU Module
Product Description:
The GE 531X309SPCAJG1 is a PACSystems™ RX3i Redundant CPU Module designed for high-availability industrial automation. It delivers fault-tolerant processing with synchronized dual-processor architecture, ensuring uninterrupted control in critical applications by automatically switching to a backup CPU during failures.
Product Parameters / Specifications (531X309SPCAJG1):
|
Feature
|
Specification / Description
|
|---|---|
|
Manufacturer
|
GE Intelligent Platforms (now part of Emerson)
|
|
Series
|
PACSystems™ RX3i (IC695 Series)
|
|
Part Number
|
531X309SPCAJG1
|
|
Module Type
|
Redundant CPU Controller
|
|
Processor
|
Dual 1.0 GHz Intel® Atom™ (Symmetric Multiprocessing)
|
|
Memory
|
512 MB DDR3 RAM / 2 GB Flash (User Program Storage)
|
|
Redundancy Mode
|
Hot Standby (µs-level switchover)
|
|
I/O Capacity
|
Supports up to 256 Modules (Mix of RX3i/RX7i)
|
|
Scan Time
|
0.1 ms/kLogic (Typical)
|
|
Communication Ports
|
2x Ethernet (10/100 Mbps), 1x Serial (RS-232/485)
|
|
Protocols
|
SRTP, Modbus TCP, Profinet, OPC UA
|
|
Backplane
|
PCI-Express (10 Gbps Synchronization Bus)
|
|
Watchdog Timer
|
Configurable 1 ms–10 s
|
|
Programming Standards
|
IEC 61131-3 (LD, FBD, ST, SFC, IL)
|
|
Safety Certification
|
SIL 2 (IEC 61508), Cat 3 (ISO 13849)
|
|
Operating Temp
|
-40°C to +70°C (Industrial)
|
|
Power Consumption
|
12W @ 5VDC (Primary), 8W (Standby)
|
|
Certifications
|
UL, CE, cULus, ATEX Zone 2
|
Key Features:
- Zero Downtime Redundancy – Seamless failover during CPU/network/power faults.
- Deterministic Control – Real-time task scheduling for motion/time-critical processes.
- Cyber Security – Built-in firewall, role-based access, and encrypted communications.
- Data Historian – Stores 100k+ tags for trend analysis.
- Hot-Swap Maintenance – Replace modules without system shutdown.
- Edge Computing – Runs C/C++/Python scripts via embedded Linux® runtime.
Primary Function & Purpose:
Provides mission-critical fault tolerance for continuous industrial processes by:
- Maintaining synchronized memory between primary/backup CPUs.
- Executing safety logic for emergency shutdowns (ESD).
- Preventing production loss during hardware failures.
Typical Applications:
- Power Plant Control – Turbine sequencing, grid synchronization.
- Oil & Gas Safety Systems – Fire/gas detection, pipeline ESD.
- Water Treatment – SCADA for pumping/filtration networks.
- Manufacturing – High-speed assembly line control.
- Transportation – Tunnel ventilation control, bridge monitoring.
Application Fields:
Deployed in 24/7 continuous operations across:
- Energy: Nuclear/Hydro power backup control, substation automation.
- Chemical Plants: Batch reactor safety interlocks.
- Minerals Processing: Conveyor/grinding mill control.
- Infrastructure: Traffic management, airport baggage systems.
