GE Electric | DS200SI0CG1A6A | Serial Input/Output Communication Module
Product Description:
The GE DS200SIOCG1A6A is a Serial Input/Output Communication Module for Speedtronic Mark V turbine control systems. It provides configurable serial communication ports (RS-232/RS-422/RS-485) to interface with HMIs, relays, sensors, and third-party devices, enabling data exchange between field equipment and the Mark V controller.
Product Parameters / Specifications (DS200SIOCG1A6A):
|
Feature
|
Specification / Description
|
|---|---|
|
Manufacturer
|
GE Energy / GE Industrial Systems
|
|
Series
|
Speedtronic Mark V Turbine Control System
|
|
Part Number
|
DS200SIOCG1A6A
|
|
Module Type
|
Serial Communication Interface Card
|
|
Primary Function
|
Bidirectional Serial Data Exchange
|
|
Communication Protocols
|
RS-232 / RS-422 / RS-485 (Software-Configurable)
|
|
Port Configuration
|
2 Independent Serial Ports
|
|
Baud Rate
|
300 bps to 115.2 kbps (Selectable)
|
|
Data Format
|
5-8 Data Bits, 1-2 Stop Bits, Parity (Even/Odd/None)
|
|
Isolation
|
1500V AC Port-to-Port & Field-to-Logic
|
|
LED Diagnostics
|
Per-Port Status (Tx/Rx/Error)
|
|
Connector Type
|
9-pin D-sub (DB9)
|
|
Redundancy Support
|
Compatible with TMR/Dual Redundant Systems
|
|
Mounting
|
Mark V I/O Pack (D/E-Series Racks)
|
|
Operating Temperature
|
-40°C to +70°C
|
|
Compliance
|
IEEE 485, IEC 61000 (EMC Immunity)
|
Key Features:
- Dual-Port Flexibility – Independent configuration for mixed-protocol operation.
- Noise Immunity – Opto-isolation and surge protection for harsh environments.
- Hot-Swap Capable – Replaceable without turbine shutdown (redundant systems).
- Protocol Adaptability – Connects to Modbus RTU, DCS, PLCs, and legacy devices.
- Real-Time Diagnostics – LED indicators for data flow and fault detection.
- SIL-2 Compliance – Supports safety-critical communication loops.
Primary Function & Purpose:
Translates serial data between field devices (e.g., sensors, HMIs) and Mark V controller logic. Enables:
- Remote monitoring of turbine parameters
- Integration with plant-wide control systems (DCS/SCADA)
- Trip signal transmission to auxiliary systems
Typical Applications & Use Cases:
- HMI Integration – Connection to operator workstations (RS-232/RS-485 links).
- Protective Relaying – Communication with generator protection devices.
- Sensor Networks – Data acquisition from vibration monitors (e.g., Bently Nevada).
- Third-Party Interfaces – Modbus RTU links to fuel control valves or emissions systems.
- Redundant Control Sync – Cross-communication between TMR processor panels.
Application Fields:
Deployed in turbine control communication networks across:
- Power Generation: Gas/steam turbines in combined-cycle plants (CCPP), nuclear auxiliaries.
- Oil & Gas: Turbine-driven compressor control and safety systems.
- Marine Propulsion: Naval vessel power management.
- Industrial Plants: Cogeneration facilities, paper mills, chemical processors.
