GE Electric | IS200AEPAH1AFD | Excitation simulation protection module
IS200AEPAH1AFD Product Overview
Functional Description:
The GE IS200AEPAH1AFD is an Excitation Analog Protection Module for GE’s Mark VI turbine control systems. It monitors generator voltage/current signals and triggers protective actions during electrical faults to safeguard turbines and power equipment.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS200AEPAH1AFD
|
|
Series
|
GE Mark VI Turbine Control System
|
|
Function
|
Generator Protection & Analog Signal Monitoring
|
|
Input Voltage
|
125 V DC via terminal block
|
|
Analog Inputs
|
12 channels (0-150V AC/DC, 0-5A AC)
|
|
Sampling Rate
|
4 kHz per channel
|
|
Relay Outputs
|
8 Form-C (5A @ 250V AC)
|
|
Accuracy
|
±0.2% FS (Voltage), ±0.5% FS (Current)
|
|
Communication
|
100 Mbps Ethernet (RJ45) + VME64x bus
|
|
Operating Temp.
|
-40°C to +70°C (-40°F to +158°F)
|
|
Protection Class
|
IP20 (chassis-mounted)
|
|
Certifications
|
UL 508, IEC 61010-1, CE
|
Product Series
- Core component of GE’s Mark VI platform for generator protection.
Key Features
- Dual-Channel Sensing: Redundant measurement for critical signals.
- Fault Detection: Under/over-voltage, phase loss, frequency deviation.
- RTD Inputs: Supports 6x Pt100 temperature sensors.
- Event Logging: Stores 512 fault records with timestamps.
- Hot-Swap Ready: Tool-free replacement during operation.
- Self-Diagnostics: Continuous hardware health monitoring.
Functions & Roles
- Generator Protection: Trips excitation during overvoltage/underfrequency.
- Analog Conditioning: Isolates & scales PT/CT signals.
- Synch Check: Validates grid synchronization.
- Harmonics Analysis: Monitors THD up to 50th order.
- Redundant Operation: Mirrored operation with paired modules.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Plants
|
Generator AVR (Automatic Voltage Regulation)
|
|
Wind Farms
|
Doubly-Fed Induction Generator (DFIG) protection
|
|
Hydroelectric
|
Excitation system backup protection
|
|
Industrial Grids
|
Cogeneration plant synchronization
|
|
Marine Power
|
Shipboard generator fault protection
|
Documentation & Support
- Manual: GEH-6421F (Mark VI Excitation Systems)
- Software: GE ToolboxST™ (v5.0+ for configuration)
- Firmware: Field-upgradable via Ethernet
- Compatibility: Interfaces with EX2100 exciters
- Safety Rating: SIL 3 (IEC 61508 for generator protection)
Critical Notes:
- Requires Mark VI controller (e.g., IS200ERPGH1A) for operation.
- Redundancy: Paired with IS200AEPAH1AFF (hot-backup module).
- Max CT Burden: 0.1 VA at 5A.
- Calibration Interval: 24 months (per IEEE 115).
- Replacement for legacy DS200AEPAG1 modules.
