IS200TRLYH1BHH Product Overview
Functional Description:
The GE IS200TRLYH1BHH is a High-Density Relay Output Module for Mark VIe turbine control systems. It provides 16 configurable Form-C relay outputs to execute safety shutdowns, alarm signaling, and equipment interlocks in power generation and industrial applications.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS200TRLYH1BHH
|
|
Series
|
Mark VIe Speedtronic™ I/O Pack
|
|
Function
|
16-Channel Relay Output Module
|
|
Relay Type
|
16x Form-C (SPDT)
|
|
Contact Rating
|
5A @ 30V DC / 2A @ 250V AC (resistive)
|
|
Isolation
|
1500V AC (channel-to-logic)
|
|
Operate Time
|
<10 ms
|
|
Safety Rating
|
SIL 2 (IEC 61508)
|
|
Communication
|
VDI Bus (to controller)
|
|
Power Supply
|
+24V DC ±10%, 0.8A (via backplane)
|
|
Operating Temp.
|
-40°C to +85°C (H variant)
|
|
Humidity
|
0–95% non-condensing
|
|
Mounting
|
IS200/IS215 I/O Pack slot (VME-compatible)
|
|
Certifications
|
UL 508, CE, IEC 61000-6-2 (EMC)
|
Product Series
- Part of Mark VIe I/O Pack Series (compatible with ,, racks).
Key Features
- LED Per Channel: Green (energized), Red (fault)
- Hot-Swappable Design: Tool-less replacement during operation
- Arc Suppression: Built-in RC snubbers for inductive loads
- Redundancy Support: Parallel operation with IS200TRLYH1BCH
- Mechanical Life: 10 million operations
- Transient Protection: 4kV surge immunity (ANSI C37.90)
Functions & Roles
- Safety Shutdown: Trip solenoids/valves upon fault detection
- Alarm Signaling: Activate horns/lights for critical events
- Equipment Interlocking: Sequence motors/pumps per safety logic
- Load Shedding: Disconnect non-critical loads during under-frequency
- Backup Control: Manual override via local pushbuttons
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Plants
|
Turbine lube oil pump control
|
|
Oil & Gas
|
Compressor emergency shutdown (ESD)
|
|
Water Treatment
|
Pump station fault isolation
|
|
Manufacturing
|
Conveyor system safety interlocks
|
|
Mining
|
Ventilation fan control
|
Documentation & Compatibility
- Manual: GEH-6850 Vol. II (Mark VIe I/O Systems)
| Software | Firmware | Controller Compatibility |
|————————|———————-|——————————|
| ToolboxST™ | MKVIe V05.03+ | IS215ACLEH1A (Mark VIe ) |
| Cimplicity™ | FPGA Rev 1.4+ | IS200ERPDH1A (Mark VIe) | - Replacement Modules:
- IS200TRLYH1BCH (Standard temp: -40°C to +70°C)
- IS215TRLYH1B (Mark VIeS compatible)
Critical Notes:
- Derating Required: Reduce current to 50% for inductive loads (e.g., solenoids)
- Voltage Limits: Never exceed 30V DC / 250V AC (contact welding risk)
- Fusing: External 5A fast-blow fuses mandatory per relay
- Simultaneous Switching: Max 8 relays activated in same cycle
- Obsolescence: Not compatible with Mark VIeS; upgrade to IS215TRLYH1B
- Wiring: Use 16 AWG shielded cable (max 50m run)
Maintenance Interval: 5 years/100k operations (per GEK-110889).
Warning: Do not use for SIL 3 functions (requires TMR module IS230TNRLH1B).
