GE Electric | IS210AEBIH1BED | Ethernet bus interface module
IS210AEBIH1BED Product Overview
Functional Description:
The GE IS210AEBIH1BED is an Enhanced Ethernet Bus Interface module for GE’s Mark VIe Speedtronic™ turbine control system. It provides redundant Ethernet communication between controllers, I/O packs, and HMIs, enabling real-time data exchange for critical power generation processes.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS210AEBIH1BED
|
|
Series
|
GE Mark VIe Turbine Control System
|
|
Function
|
Dual-Port Ethernet Switch & Bus Interface
|
|
Voltage Input
|
24 V DC (±10%) via backplane
|
|
Communication
|
2x 1 Gbps Ethernet (RJ45) + 1x 100 Mbps (ST fiber)
|
|
Protocols
|
TCP/IP, IEC 61850-3, Modbus TCP, SRTP
|
|
Switching Speed
|
< 5 µs latency
|
|
Operating Temp.
|
-40°C to +70°C (-40°F to +158°F)
|
|
Redundancy
|
RSTP (Rapid Spanning Tree Protocol)
|
|
Certifications
|
UL 508, CE, IEC 61131-2, IEEE 1613
|
|
MTBF
|
> 250,000 hours
|
Product Series
- Core component of GE’s Mark VIe platform (successor to Mark VI), designed for gas/steam/hydro turbine control.
Key Features
- Dual-Star Topology: Isolated paths for fault tolerance.
- Cyber Security: IEEE 802.1X authentication, VLAN tagging.
- Deterministic Traffic: QoS prioritization for critical data.
- Fiber Optic Support: 100 Mbps ST connector for EMI immunity.
- Hot-Swappable: Tool-less replacement without shutdown.
- Real-Time Diagnostics: Port status LEDs, SNMP monitoring.
Functions & Roles
- Network Aggregation: Connects up to 24 devices (controllers, I/O, drives).
- Data Synchronization: Coordinates turbine/generator control logic.
- Fault Isolation: Segments network failures via RSTP.
- Time Synchronization: Supports IEEE 1588 PTP (Precision Time Protocol).
- HMI Integration: Streamlines data to CIMPLICITY®/iFIX® HMIs.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Generation
|
Gas/Steam Turbine Control Networks
|
|
Hydroelectric
|
Dam Control Systems
|
|
Oil & Gas
|
Compressor Station Automation
|
|
Wind Energy
|
Wind Farm SCADA Communication
|
|
Industrial
|
High-Reliability Process Control Networks
|
Documentation & Support
- Manual: GEH-6858 (Mark VIe System Guide)
- Software: GE ToolboxST™ (v8.0+ for Mark VIe)
- Compatibility: Works with EX2100e excitation, DS3800 drives
- Lifecycle Status: Active (GE P/N: 9AM00AEBIH1BED)
- Firmware Updates: Via GE Support website
Critical Notes:
- Requires Mark VIe controller (e.g., IS210ERTKGH1A) for operation.
- Replacement for legacy IS200ERBG modules.
- Supports redundant power supplies (24V DC ±10%).
There are no reviews yet.
