GE Electric | IS210BPPBH2BMD | Power plant busbar protection board (PPB) module
IS210BPPBH2BMD Product Overview
Functional Description:
The IS210BPPBH2BMD is a Power Plant Bus Protection Board (PPB) module designed for GE’s Mark VIe series turbine control systems. It serves as a critical interface for monitoring and protecting electrical power plant bus systems by managing analog/digital I/O signals, executing protective logic, and communicating with other components within the distributed control architecture.
Key Parameters & Specifications (Tabulated)
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS210BPPBH2BMD
|
|
Series
|
GE Mark VIe Speedtronic™ Turbine Control System
|
|
Function
|
Bus Protection & Power Management
|
|
Input Voltage
|
24 V DC (Typical, via backplane)
|
|
Communication
|
Ethernet (SRTP), Genius Bus
|
|
I/O Channels
|
16+ digital I/O, 8+ analog inputs
|
|
Operating Temp.
|
-40°C to +70°C (-40°F to +158°F)
|
|
Mounting
|
DIN rail or panel mount (within Mark VIe rack)
|
|
Compliance
|
IEC 61850 (Grid Protection Standards), UL/cUL, CE
|
Product Series
- Mark VIe Platform: Part of GE’s Speedtronic™ family for steam/gas turbine control, safety monitoring, and power management in industrial/energy applications.
Key Features
- Dual Redundant Ethernet: For high-availability communication.
- Real-Time Fault Detection: Monitors bus voltage/frequency, phase imbalances, and overloads.
- Protective Relaying Logic: Executes trip commands for grid faults (e.g., under/over-voltage, islanding).
- Hot-Swappable Design: Supports replacement without system shutdown.
- Secure Firmware: Digitally signed updates via GE ToolboxST™ software.
- LED Status Indicators: Visual health/troubleshooting diagnostics.
Functions & Roles
- Bus Protection: Triggers breaker trips during electrical faults.
- Power Quality Monitoring: Tracks voltage, frequency, harmonics.
- Synchro-Check: Validates synchronization before grid reconnection.
- Data Logging: Records event sequences for failure analysis.
- Hardware Interfacing: Integrates with CTs/PTs (current/potential transformers).
Applications & Use Cases
- Power Generation Plants:
- Gas/Steam Turbine Generator Protection.
- Grid Synchronization Management.
- Industrial Energy Systems:
- Cogeneration Facilities (CHP).
- Critical Bus Protection in Petrochemical Plants.
- Renewable Integration:
- Wind/Solar Farm Substation Control.
- Microgrid Islanding Detection.
Documentation & Support
- Manual: GEH-6855 (Mark VIe Functional Safety Guide).
- Configuration Software: GE ToolboxST™.
- Datasheet: GE IS210BPPBH2BMD Product Guide (Official Link).
