GE Electric | IS210BPPBH2CAA | Breaker Protection and Control Module
IS210BPPBH2CAA Product Overview
Functional Description:
The GE IS210BPPBH2CAA is a Breaker Protection and Control Module for GE Mark VIe industrial control systems. It provides comprehensive protection, monitoring, and control functions for circuit breakers in power distribution networks, integrating metering, fault detection, and trip logic in a single module.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS210BPPBH2CAA
|
|
Series
|
Mark VIe Speedtronic Turbine Control
|
|
Function
|
Breaker Protection & Control
|
|
Input Voltage
|
48–125 V DC (control power)
|
|
Current Inputs
|
3-phase (via CTs), 1A/5A configurable
|
|
Voltage Inputs
|
3-phase (via PTs), 120/690V AC
|
|
Protection Functions
|
50/51 (Overcurrent), 50N/51N (Ground), 27/59 (Under/Overvoltage)
|
|
Trip Outputs
|
4× Form-C relays (5A, 250 V AC)
|
|
Accuracy
|
±0.5% (voltage/current), ±10 ms (trip)
|
|
Comm Protocols
|
Modbus TCP, Profibus DP, IEC 61850
|
|
Isolation
|
2.5 kV AC (inputs/outputs)
|
|
Operating Temp.
|
-30°C to +65°C
|
|
Mounting
|
DIN rail (standard)
|
|
Certifications
|
UL 1053, IEEE C37.90, IEC 60255
|
Product Series
- Core module in Mark VIe Protection Series (compatible with EX2100 excitation systems).
Key Features
- Multi-Function Protection: 12+ ANSI protection functions (67/81U/81O supported).
- Synchrocheck: Voltage/frequency/phase matching for breaker closure.
- Disturbance Recorder: 128-cycle event capture at 1 kHz sampling.
- Arc-Flash Reduction: Zone-selective interlocking (ZSI) capability.
- Self-Monitoring: Watchdog timer, RAM/ROM diagnostics.
- HMI Integration: Front RS-232 port for local configuration.
Functions & Roles
- Fault Detection: Instantaneous/time-delayed trip for overcurrent, ground faults.
- Breaker Control: Open/close commands via relay outputs.
- Power Metering: RMS voltage/current, kWh, PF, frequency.
- Auto-Reclosing: Programmable sequence (up to 4 shots).
- Event Logging: 500+ time-stamped alarms & SOE records.
Applications & Use Cases
|
Industry
|
Application
|
|---|---|
|
Power Plants
|
Generator circuit breaker protection
|
|
Substations
|
Feeder/motor protection in switchgear
|
|
Oil & Gas
|
HV/LV distribution panel protection
|
|
Industrial Plants
|
Critical bus tie-breaker control
|
|
Renewables
|
Wind farm collector breaker management
|
Documentation & Support
- Manual: GEH-6856 (Mark VIe Protection Modules)
| Compatible Systems | Configuration Tool |
|————————|——————————-|
| Mark VIe, EX2100e | GE ToolboxST™ (Protection Manager) | - Firmware: Upgradable via Ethernet (TFTP)
- Replacement: IS210BPPBH2Cxx series (xx = revision)
Critical Notes:
- CT Requirements: Burden ≤ 0.1 VA at 1A secondary.
- Trip Circuit Supervision: Requires external 48 V DC supply.
- Settings Backup: Non-volatile memory retains settings during power loss.
- Safety: Conforms to ANSI/IEEE C37.90.1 (surge immunity).
- Derating: Max ambient temp 55°C for full load.
- Legacy Compatibility: Replaces GE SR750 protection relays.
