GE Electric | IS210BPPCH1AD | Programmable Protection & Control Module
IS210BPPCH1AD Product Overview
Functional Description:
The GE IS210BPPCH1AD is a Programmable Protection & Control Module from the Mark VIe series, designed to manage critical protection logic and real-time I/O processing for gas/steam turbines. It interfaces with sensors, actuators, and networks to execute safety shutdowns, speed control, and fault diagnostics in industrial power systems.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Part Number
|
IS210BPPCH1AD
|
|
Series
|
GE Mark VIe Speedtronic™ Turbine Control System
|
|
Function
|
Turbine Protection & Control Logic Execution
|
|
Input Voltage
|
24 V DC (±10%) via backplane
|
|
Communication
|
Dual Ethernet (SRTP), IEC 61850-3 compliant
|
|
I/O Capacity
|
32 digital I/O, 16 analog inputs (configurable)
|
|
Processor
|
TriCore™ 32-bit RISC
|
|
Operating Temp.
|
-30°C to +65°C (-22°F to +149°F)
|
|
Certifications
|
UL 508, CE, IEC 61131-2, SIL 2 (Safety Integrity)
|
|
Firmware Management
|
GE ToolboxST™ software (v8.0+)
|
Product Series
- Part of GE’s Mark VIe platform for integrated turbine management, leveraging modular, distributed architecture for power generation and industrial processes.
Key Features
- Triple Modular Redundancy (TMR) Support: For fault-tolerant critical control.
- High-Speed Logic Execution: <10 ms response time for trip commands.
- Secure Communications: AES-128 encryption for network data.
- Hot-Swap Capability: Module replacement without turbine shutdown.
- Built-in Diagnostics: Continuous health monitoring (LED alarms for faults).
- IEEE 1588 Precision Time Protocol: Synchronized timing across control networks.
Functions & Roles
- Turbine Protection: Triggers emergency stops on overspeed, vibration, or temperature excursions.
- Sequential Control: Manages startup/shutdown sequences and fuel valves.
- Analog Signal Processing: Interfaces with PT100 thermocouples, 4-20mA pressure sensors.
- Data Historian: Stores 90+ days of operational logs for incident analysis.
- Modbus TCP/RTU Gateway: Legacy system integration.
Applications & Use Cases
- Power Generation:
- Gas/Steam Turbine Protection (Combined Cycle Plants).
- Generator Excitation Control.
- Oil & Gas:
- Compressor Station Control (Pipeline Operations).
- Offshore Platform Turbine Safety Systems.
- Industrial:
- Cogeneration (CHP) Plants.
- Critical Machinery Overspeed Protection.
- Grid Stability:
- Frequency Regulation & Load Shedding.
Documentation & Support
- Manual: GEH-6856 (Mark VIe Control Functions).
- Configuration: GE ToolboxST™ (Logic Builder, HMI Integration).
- Compatibility: Works with Mark VIe I/O packs (e.g., IS200/IS215 series).
- Datasheet: GE Digital Support Portal (Search by part number).
There are no reviews yet.
