GE IC695CPE400-ABAB Programmable Automation Controller (PAC) CPU module
GE IC695CPE400-ABAB – Product Overview
The GE IC695CPE400-ABAB is a high-performance Programmable Automation Controller (PAC) CPU module within GE’s RX3i Series. Designed for mission-critical industrial automation, this controller features real-time processing capabilities, embedded Ethernet communications, and extensive I/O support for complex control applications across demanding environments.
Key Parameters & Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer Part No.
|
IC695CPE400-ABAB
(ABAB suffix = firmware bundle) |
|
Product Type
|
PACSystems RX3i CPU Module
|
|
Processor
|
1.0 GHz Intel Celeron M (Dual-core)
|
|
Memory
|
• 512 MB DDR2 RAM
• 512 MB Flash (User Program + OS) |
|
I/O Capacity
|
• Max. 512 Local I/O Modules
• Up to 32,000 Discrete I/O Points • 4,000 Analog Points |
|
Communication Ports
|
• Embedded Dual Ethernet: 10/100BASE-TX (Port 1: CPU Sync/IP, Port 2: LAN)
• Serial RS-232/485 (RS-232 default) |
|
Protocol Support
|
• SRTP (Serial Real-Time Protocol)
• Modbus TCP/RTU • PROFINET Controller/Device (optional firmware) • EtherNet/IP |
|
Backplane Speed
|
PCI Express (1.5 GB/s)
|
|
Battery Backup
|
CR2032 Lithium (Retains RAM during power loss)
|
|
Task Execution Time
|
0.1 ms typical (Boolean instruction)
|
|
Operating Temperature
|
0°C to +60°C
|
|
Power Consumption
|
8W @ 5VDC (Typical)
|
|
Certifications
|
UL 508, cULus, CE, RoHS, IEC 61131-2
|
|
Firmware Bundle
|
Proficy Machine Edition (PME) v8.0+ Runtime
|
Series & Family
- Series: PACSystems RX3i (Modular Platform)
- Generation: RX3i Performance Series CPUs (Post-2015)
- Compatible Backplanes: IC695CHS012 (12-slot), IC695CHS016 (16-slot)
- Related CPUs: IC695CPE310 (Lower Tier), IC695CPE305 (Economy), IC695CPE040 (High-End)
Key Features
- Deterministic Control: Hardware-based task scheduling for <±1µs jitter
- Dual Ethernet Ports: Built-in switch for daisy-chaining devices (Ring/DLR support)
- Cyber Security: Password protection, role-based access, audit trails
- Hot Standby Redundancy: Supports CPU-to-CPU mirroring (IC695CRE040)
- Motion Control: Integrated SERCOS III interface (via expansion)
- Data Logging: On-CPU historical storage (SQLite compatible)
- Firmware Resilience: Dual-bank flash for failsafe updates
Function & Role
- Central Processing: Executes ladder logic, structured text, C/C++ blocks
- Network Coordination: Manages PROFINET/EtherNet/IP device networks
- I/O Data Management: Processes real-time I/O scans across backplane
- System Diagnostics: Monitors module health, network traffic, and fault states
- Security Gateway: Implements VLAN segmentation and firewall rules
Primary Applications
- High-speed machine control (packaging, CNC)
- Process automation (PID loops, batch sequencing)
- Motion control (robotics, servo positioning)
- SCADA/HMI integration
- Energy management systems
Application Fields
|
Industry
|
Use Cases
|
|---|---|
|
Automotive
|
Body-in-white assembly, test stands
|
|
Food & Beverage
|
CIP systems, filling lines, pasteurization
|
|
Pharmaceutical
|
Batch reactor control, cleanroom monitoring
|
|
Power Generation
|
Turbine auxiliaries, switchgear control
|
|
Water/Wastewater
|
Pump station optimization, chemical dosing
|
|
Oil & Gas
|
Pipeline SCADA, compressor control
|
Critical Notes:
- Firmware Bundle: “ABAB” includes PME v8.0 Runtime + PROFINET Controller license
- Redundancy: Requires IC695CRE040 Redundancy Module for hot-backup
- Motion Control: Needs IC694MDL645 SERCOS III interface module
- Legacy Migration: Supports Series 90-30/90-70 I/O via IC694ACC300 adapters
- Lifecycle Status: Active production (as of 2024), successor = IC695CPE440
