GE IS200AEPGG1AAA Exciter power module
GE IS200AEPGG1AAA Technical Specification
Specification
|
Attribute
|
Detail
|
|---|---|
|
Part Number
|
|
|
Manufacturer
|
General Electric (GE)
|
|
Series
|
Mark VIe Speedtronic™
|
|
Country of Origin
|
USA
|
|
Function
|
Exciter Power Supply Module
|
Description
The GE IS200AEPGG1AAA is a high-reliability exciter power supply module designed for GE’s Mark VIe turbine control systems. It delivers regulated DC power to generator field windings, ensuring stable excitation voltage/current for synchronous machines. The module features integrated diagnostics, redundancy support, and rugged construction for critical power generation applications.
Features
- Dual-Channel Input: Accepts 120/240V AC or 125V DC inputs with automatic source switching.
- High-Current Output: Supplies 125V DC at 25A continuous (30A peak) to excitation systems.
- Auto-Feedback Control: Internal voltage/current regulation (±0.25% accuracy).
- Redundant Operation: Parallel-capable for N+1 configurations (active load sharing).
- Robust Design: Operates at -30°C to +65°C (-22°F to +149°F) with 95% non-condensing humidity (IEC 60068-2).
- Protections: Over-voltage, over-current, short-circuit, and overtemperature safeguards.
- Front-Panel Indicators: LED status for power, faults, and load activity.
Electrical Characteristics
|
Parameter
|
Specification
|
|---|---|
|
Input Voltage
|
120/240V AC ±10% or 125V DC ±20%
|
|
Output Voltage
|
125V DC (±0.5% ripple)
|
|
Output Current
|
25A continuous, 30A (30-sec overload)
|
|
Efficiency
|
>92% (full load)
|
|
Response Time
|
<5ms for load transients
|
Product Properties
|
Property
|
Specification
|
|---|---|
|
Cooling Method
|
Convection/forced air (integrated fan)
|
|
Communication
|
Hardware status signals via backplane
|
|
Redundancy Support
|
Active parallel operation (N+1)
|
|
Control Interface
|
Mark VIe backplane integration (ICM/ICN)
|
|
Safety Certification
|
UL 508, IEC 62103, CE, Class I Div 2 (hazardous)
|
|
Dimensions
|
200 × 150 × 75 mm (7.9 × 5.9 × 3.0 in)
|
|
Weight
|
2.3 kg (5.1 lbs)
|
Power Consumption & Heat Dissipation
|
Mode
|
Value
|
|---|---|
|
No-Load Input Power
|
<15W
|
|
Full-Load Input Power
|
3.4 kW (max)
|
|
Heat Dissipation
|
250W (typical at 25A)
|
Key Applications
- Power Plants: Excitation for gas/steam turbine generators.
- Hydroelectric Systems: Field current regulation for hydro-generators.
- Industrial Drives: Synchronous motor excitation in compressors/pumps.
- Marine Propulsion: Redundant power for shipboard generators.
⚠️ Integration Note:
- Requires Mark VIe controller (IS200/IS215) for regulation commands.
- Replace fans every 50,000 hours (MTBF: 300,000 hours).
- Arc-flash mitigation compliant per IEEE C37.20.7.
There are no reviews yet.
