GE IS200STCIH6AED is a robust simplex contact input terminal board belonging to GE’s Series 300, specifically engineered for the Mark VI and Mark VIe Speedtronic control systems. It functions as a key interface for gas and steam heavy – duty turbines, scaling and conditioning diverse signals like 4 – 20mA analog signals, thermocouple inputs, and discrete I/O signals from field sensors and actuators. With high galvanic isolation, industrial – grade components, and compatibility with protocols such as RS485 and CAN bus, it ensures stable and accurate signal transmission even in harsh industrial settings (-40°C to +85°C operating range). Its modular design allows for easy installation and maintenance, while seamless integration with GE’s turbine control systems and support for remote diagnostics help minimize downtime. This module is widely applied in power generation, oil & gas, and chemical sectors, serving as a vital component to guarantee reliable operation and safety of turbine systems.
STAI INSTALLATION:
A sheet metal carrier that is mounted on a DIN rail carries the STAI together with a plastic insulator. The STAI plus insulator can alternatively mount to a sheet metal assembly before being fastened directly to a cabinet. There are two different varieties of Euro-block terminal blocks available:
- A permanently mounted terminal block with 48 terminals is present on STAI 1.
- A right-angle header on STAI 2 accepts a variety of pluggable terminal blocks that are readily accessible and have a total of 48 terminals.
- Typically, shielded twisted pair (#18 AWG) wires are utilized. There is an I/O cable shield terminal available next to the terminal blocks.
It is possible to accept the following analog input and output types:
- Two-wire transmitter with analog input.
- Three-wire transmitter with analog input.
- Four-wire transmitter with analog input.
- An externally powered transmitter with an analog input.
- Analog input, 5 and 10 volts direct current.
- 0-20 mA current analog output.
- Analog output, current of 0-200 mA.
