GE IS200VTCCH1CBB is a high-performance thermocouple input terminal board belonging to the Mark VI series, specifically engineered for GE’s turbine control systems that manage gas, steam, and wind turbine automation. It supports E, J, K, S, and T type thermocouples and can accommodate up to 24 thermocouple inputs, while conditioning and processing relevant temperature signals for reliable data acquisition. The board is compatible with both simplex and triple modular redundant control, interfaces seamlessly with DTTC and TBTC terminal boards, and features a conformal PCB coating to boost durability in harsh industrial settings. As a key component in power generation, petrochemical and other fields, it ensures accurate temperature monitoring and stable operation of turbine systems, facilitating efficient and safe control of turbine operation throughout various working conditions.
STAI INSTALLATION:
A sheet metal carrier that is mounted on a DIN rail carries the STAI together with a plastic insulator. The STAI plus insulator can alternatively mount to a sheet metal assembly before being fastened directly to a cabinet. There are two different varieties of Euro-block terminal blocks available:
- A permanently mounted terminal block with 48 terminals is present on STAI 1.
- A right-angle header on STAI 2 accepts a variety of pluggable terminal blocks that are readily accessible and have a total of 48 terminals.
- Typically, shielded twisted pair (#18 AWG) wires are utilized. There is an I/O cable shield terminal available next to the terminal blocks.
It is possible to accept the following analog input and output types:
- Two-wire transmitter with analog input.
- Three-wire transmitter with analog input.
- Four-wire transmitter with analog input.
- An externally powered transmitter with an analog input.
- Analog input, 5 and 10 volts direct current.
- 0-20 mA current analog output.
- Analog output, current of 0-200 mA.
