GE IS215UCCCM04A Communication Module
1. Product Description
The GE IS215UCCCM04A is a Communication Module for GE’s Mark VIe turbine control system. It enables high-speed data exchange between the controller core (e.g., IS200ERPGH1A) and external networks/devices, supporting critical protocols for industrial automation.
2. Key Parameters & Specifications
|
Category
|
Specification
|
|---|---|
|
Part Number
|
|
|
Series
|
Mark VIe Speedtronic™ Control System
|
|
Type
|
Controller Communication Module
|
|
Processor
|
PowerPC-based, 500+ MHz
|
|
Memory
|
256 MB RAM, 512 MB Flash
|
|
Communication Ports
|
2x Ethernet (RJ45), RS-232/485 Serial, USB 2.0
|
|
Protocols Supported
|
Modbus TCP/RTU, DNP3, IEC 60870-5-104, OPC UA, EtherNet/IP
|
|
Power Requirement
|
24V DC (±10%) via backplane; 8W typical
|
|
Operating Temperature
|
-40°C to +70°C (-40°F to +158°F)
|
|
Certifications
|
UL 508, CE, IEC 61800-5-1 (SIL 2), RoHS
|
|
Dimensions
|
160 x 130 x 45 mm (6.3 x 5.1 x 1.8 in)
|
|
MTBF
|
>300,000 hours
|
3. Series & Variants
- Series: Part of GE Mark VIe UCCC Series (Universal Controller Communication Modules).
- Variants:
- IS215UCCCM03A: Earlier version with reduced memory (128 MB RAM).
- IS215UCCCH4A: Enhanced security version with hardware encryption.
4. Key Features
- Multi-Protocol Gateway: Translates between Modbus, DNP3, IEC 60870, and OPC UA.
- Redundant Networking: Supports hot-standby communication paths.
- Secure Data Transfer: TLS/SSL encryption, user authentication, and role-based access.
- Real-Time Clock: Synchronized via IEEE 1588 PTP protocol.
- Diagnostic Tools: On-board LEDs, Syslog, SNMP v3 monitoring.
- Hot-Swappable: Replaceable without system shutdown.
5. Function & Role
- Data Bridging: Connects Mark VIe controllers to SCADA, DCS, and plant networks.
- Protocol Conversion: Interfaces legacy devices (e.g., RTUs) with modern Ethernet systems.
- Cybersecurity Firewall: Filters unauthorized traffic between control and enterprise networks.
- Time Synchronization: Coordinates timestamped data across the control system.
6. Applications & Use Cases
|
Application Domain
|
Function
|
|---|---|
|
Power Generation
|
Integrates gas/steam turbines with plant SCADA (e.g., CIMPLICITY, Ovation).
|
|
Oil & Gas
|
Connects compressors/PLC systems to centralized control rooms.
|
|
Water Treatment
|
Bridges PLCs (RX3i, VersaMax) to HMI/analytics platforms.
|
|
Renewable Energy
|
Interfaces wind/solar farm controllers to grid management systems.
|
|
Industrial IoT
|
Enables secure data transfer to cloud platforms (Predix, Azure IoT).
|
7. Comparison to Similar Modules
|
Feature
|
IS215UCCCM04A
|
IS215UCCCM03A
|
|---|---|---|
|
Memory
|
256 MB RAM / 512 MB Flash
|
128 MB RAM / 256 MB Flash
|
|
Protocols
|
OPC UA, IEC 60870-5-104
|
Modbus, DNP3 only
|
|
Security
|
TLS/SSL, Hardware Firewall
|
Basic password protection
|
|
Operating Temp
|
-40°C to +70°C
|
-30°C to +60°C
|
Summary
The GE IS215UCCCM04A is a critical communication interface in Mark VIe turbine control systems, providing secure, multi-protocol connectivity between controllers and higher-level networks. Its rugged design and SIL 2 certification make it ideal for mission-critical applications in power generation, oil & gas, and industrial automation.
️ Configuration Note: Requires ToolboxST™ software (v08.20+) for setup. Integrates with Mark VIe controllers via VDOK connector. For lifecycle support, contact GE Power Services.
System Integration Diagram
Mark VIe Controller (e.g., IS215ACLEH1A)
↑
IS215UCCCM04A → Plant Ethernet Switch → SCADA/DCS
↓
Legacy Devices (Modbus RTU, DNP3)
