GE WEA13-13 2508-21001 Universal coil electromechanical relay
GE WEA13-13 2508-21001 Technical Specification
(Multi-Voltage Electromechanical Relay Module)
Specification
|
Attribute
|
Detail
|
|---|---|
|
Part Number
|
WEA13-13 (2508-21001 variant)
|
|
Manufacturer
|
General Electric (GE)
|
|
Series
|
WEA Industrial Relay Series
|
|
Country of Origin
|
Hungary (GE Tungsram)
|
|
Function
|
Heavy-Duty Power Switching Relay
|
Description
The GE WEA13-13 2508-21001 is a universal-coil electromechanical relay with 4PDT (4 Form C) contacts designed for industrial control circuits. Features wide-voltage compatibility (24–240V AC/DC) and 10A switching capacity. Sealed construction resists dust, humidity, and corrosive gases in turbine control panels and locomotive systems.
Features
- Electrical Flexibility:
- Multi-Voltage Coil: 24–48V DC / 48–240V AC (50/60Hz)
- Contact Configuration: 4 Form C (4PDT)
- LED Status Indicator: Red (energized) / Green (de-energized)
- Robust Construction:
- Hermetically sealed contacts (nitrogen-filled)
- -40°C to +85°C operational range
±8kV surge immunity (IEC 61000-4-5)
- Safety Compliance:
- SIL 3 (IEC 61508) / CAT III (600V)
| Model Variations | WEA13-13 (2508-21001) | Standard WEA13 |
|—————————-|—————————-|——————–|
| Contact Material | AgCdO (anti-welding) | AgNi |
| Terminal Type | Screw clamp (Cu alloy) | Solder lug |
- SIL 3 (IEC 61508) / CAT III (600V)
Electrical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Contact Rating
|
10A @ 250V AC (resistive) / 6A @ 30V DC
|
|
Max Switching Voltage
|
600V AC / 250V DC
|
|
Max Inrush Current
|
40A (20ms)
|
|
Coil Power Consumption
|
1.2W (DC) / 3.5VA (AC)
|
|
Contact Resistance
|
<50 mΩ (initial)
|
|
Insulation Resistance
|
>1000 MΩ (500V DC)
|
|
Switching Time
|
<15 ms (operate) / <10 ms (release)
|
Product Properties
|
Property
|
Specification
|
|---|---|
|
Enclosure Rating
|
IP67 (dust/waterproof)
|
|
Terminals
|
13-pin (ISO 50017-13 screw clamp)
|
|
Material
|
PBT thermoplastic housing, stainless steel spring
|
|
Dimensions
|
29 × 65 × 53 mm (1.1 × 2.6 × 2.1 in)
|
|
Weight
|
120 g (0.26 lbs)
|
|
Mechanical Life
|
10⁷ operations
|
|
Electrical Life
|
10⁵ operations (10A resistive)
|
Thermal Derating Curve
|
Ambient Temperature
|
Max Continuous Current
|
|---|---|
|
20°C
|
10A
|
|
50°C
|
8.5A
|
|
70°C
|
6A
|
|
85°C
|
4A (intermittent only)
|
Key Applications
- Turbine Protection Circuits:
- Lube oil pump interlocks (Mark VIe controllers)
- Generator breaker trip coils
- Railway Signaling:
- Track circuit control (GE VitalLogic systems)
- Level crossing gate motors
- Industrial Automation:
- Conveyor emergency stop circuits
| Industry | Typical Load |
|———————–|———————————-|
| Power Generation | Solenoid valves (12A inrush) |
| Oil & Gas | Gas detector alarms (24V DC) |
| Water Treatment | Chemical dosing pumps (240V AC) |
- Conveyor emergency stop circuits
️ Critical Integration Notes:
- Coil Suppression:
- DC Coils: Install 1N4007 diode across coil terminals (cathode to +)
- AC Coils: Use RC snubber (100Ω + 0.1μF 250V) to suppress arcing
- Contact Protection:
- For inductive loads (contactors/relays): Add varistor (V130LA20AP) across contacts
- For lamp/motor loads: Derate to 60% of nominal current
- Installation:
- Maintain ≥15 mm clearance between adjacent relays for heat dissipation
- Torque terminals to 0.6 N·m – overtightening cracks housing
- Fail-Safe Design:
- Configure NC contacts for critical shutdown paths (failsafe on coil loss)
- Avoid parallel contacts for current sharing – use interposing relays instead
- Maintenance:
- Replace after 100,000 cycles or 5 years (whichever first) in high-vibration environments
- Clean terminals annually with contact enhancer (CX-80) to prevent oxidation
- Safety Compliance:
- SIL 3 applications require dual-channel wiring (two relays in series)
- UL 508 isolation barriers needed when switching >150V AC
