Hilscher CIFX 50-CO Product Introduction

1. General Information

The Hilscher CIFX 50-CO is a high-performance communication interface module designed for industrial automation systems. As a key component in Hilscher’s CIFX series, it enables seamless integration of industrial controllers into various fieldbus and industrial Ethernet networks, facilitating reliable data exchange between different automation components. Its compact design and robust construction make it suitable for deployment in harsh industrial environments, ensuring stable operation in applications ranging from manufacturing plants to process control systems.

2. Product Parameters

Parameter	Details
Part Number	CIFX 50-CO
Manufacturer	Hilscher GmbH
Form Factor	Compact module, DIN rail mountable
Processor	32-bit RISC processor with high clock speed
Memory	Flash memory: Up to 8 MB; RAM: Up to 16 MB
Supported Protocols	PROFINET IO Device, EtherNet/IP Adapter, Modbus TCP, PROFIBUS DP Slave, DeviceNet Slave
Operating Voltage	24 V DC ± 20%
Current Consumption	Typical: 120 mA @ 24 V DC; Maximum: 180 mA @ 24 V DC
Operating Temperature	-40 °C to +70 °C
Storage Temperature	-40 °C to +85 °C
Humidity Resistance	5% to 95% RH, non-condensing
Vibration Resistance	10 g (10 Hz to 150 Hz)
Shock Resistance	50 g (11 ms duration)
Protection Class	IP20 (when mounted in a control cabinet)
Dimensions (L x W x H)	Approximately 100 mm x 35 mm x 120 mm

3. Product Specifications

3.1 Communication Capabilities

The CIFX 50-CO supports multiple industrial communication protocols, allowing it to act as a bridge between controllers and various field devices. For PROFINET IO Device, it complies with IEC 61158 and IEC 61784 standards, supporting data transfer rates up to 100 Mbps full-duplex. As an EtherNet/IP Adapter, it adheres to ODVA specifications, enabling seamless integration into Rockwell Automation-based systems. The Modbus TCP protocol support includes both client and server modes, with a maximum data frame size of 2048 bytes. For PROFIBUS DP Slave, it supports baud rates from 9.6 kbps to 12 Mbps, with a maximum of 244 bytes of input and output data. DeviceNet Slave functionality complies with CANopen standards, supporting baud rates of 125 kbps, 250 kbps, and 500 kbps.

3.2 Hardware Design

The module features a rugged metal housing that provides electromagnetic interference (EMI) shielding, ensuring reliable operation in environments with high levels of electrical noise. It is equipped with a standard M12 Ethernet port for network connectivity and a 7-pin terminal block for power supply and auxiliary signals. The DIN rail mounting design allows for easy installation in standard control cabinets, saving space and simplifying system integration. Internal overvoltage and reverse polarity protection for the power supply prevent damage from electrical faults, enhancing the module’s durability.

3.3 Diagnostic and Monitoring Functions

The CIFX 50-CO incorporates advanced diagnostic features to facilitate system troubleshooting. It provides real-time status indicators for power, network connectivity, and protocol-specific errors via LED lights. Detailed diagnostic data, including error codes, communication statistics, and voltage levels, can be accessed through a web-based management interface or via the controller using protocol-specific diagnostic messages. This enables maintenance personnel to quickly identify and resolve issues, minimizing downtime in industrial operations.

4. Features

4.1 Multi-Protocol Flexibility

One of the key features of the CIFX 50-CO is its ability to support multiple industrial protocols, eliminating the need for separate interface modules for different networks. This flexibility allows system integrators to use a single module in diverse automation environments, reducing inventory costs and simplifying system design. The protocol configuration can be easily adjusted using Hilscher’s powerful configuration software, enabling quick adaptation to changing network requirements.

4.2 High Reliability and Durability

Designed to meet strict industrial standards, the CIFX 50-CO offers exceptional reliability in harsh operating conditions. Its wide operating temperature range (-40 °C to +70 °C) and resistance to vibration, shock, and humidity ensure stable performance in applications such as automotive manufacturing, chemical processing, and oil and gas production. The robust hardware design, including EMI shielding and power protection features, further enhances its ability to withstand industrial environments.

4.3 Easy Integration and Configuration

The module is designed for seamless integration into existing automation systems. It supports standard industrial interfaces and can be easily connected to PLCs, DCSs, and other controllers. Hilscher’s intuitive configuration software provides a user-friendly interface for setting up protocols, adjusting parameters, and monitoring module status. The web-based management interface allows for remote configuration and diagnostics, reducing the need for on-site maintenance and improving operational efficiency.

4.4 High-Speed Data Transfer

With support for high-speed industrial Ethernet protocols (up to 100 Mbps), the CIFX 50-CO ensures fast and deterministic data exchange between controllers and field devices. This is critical for time-sensitive applications such as motion control and real-time process monitoring, where accurate and timely data transmission is essential for maintaining system performance and product quality.
