The HIMA F8650X is a core CPU module for HIMA’s HIQuad X and HIMax safety PLC systems, tailored for critical safety instrumented systems (SIS) in industrial settings. It meets IEC 61508 SIL 3 and ISO 13849 PL e Cat.4 standards, featuring two clock – synchronized Intel 386EX 32-bit microprocessors running at 25 MHz, each equipped with 1MB Flash-EPROM for the OS and user programs, plus a total of 1MB data SRAM. The module is powered by a 5V DC backplane bus with a typical power consumption of around 10W, and operates stably within a temperature range of -20°C to +60°C. It has two electrically isolated RS485 interfaces and can achieve Ethernet and Modbus TCP communication when paired with the F8627X module. With a 4-digit alphanumeric display and LED indicators for fault diagnosis, it supports redundant configuration and has a safety – related watchdog with short – circuit protection. Widely used in oil and gas, chemical and power industries, it serves as the core of ESD and HIPPS to ensure safe industrial operations.
The characteristics of this module are mainly reflected in the following aspects:
Wide range of power supply voltage: This module can operate within the voltage range of 20 to 32V DC, and the on-site voltage range is also between 18 to 32V DC. In addition, it can withstand a maximum voltage of -1 to 40V DC, which allows it to operate stably in various industrial environments.
Strong fault tolerance in circuit design: This module adopts a fault-tolerant design with completely triple selectable circuits, that is, there are three identical circuits working simultaneously inside the module. This design can effectively ensure the correctness and reliability of the output, even if some circuits fail, other circuits can continue to work normally.
Multiple monitoring outputs: This module has 40 independent channels, each of which can be used for monitoring and output. This allows it to process multiple input and output signals simultaneously, improving work efficiency.
Flexible power pack allocation: The module is divided into 8 independent power packs, each with 5 working outputs. The design of this power pack makes the distribution of electricity more flexible, and the output of each power pack can be adjusted according to actual needs.
High rated output current: The rated output current of each channel of each power pack is 2A, and the total maximum output current is 8A. This makes the module perform well when driving high-power devices.
