Hirschmann MM20-Z6Z6Z6Z6SAHH Industrial Ethernet Switch – Technical Product Overview

The Hirschmann MM20-Z6Z6Z6Z6SAHH is a high-performance, ruggedized industrial Ethernet switch designed for mission-critical applications in harsh environments. Built to deliver reliable connectivity and exceptional durability, this switch is ideal for industries such as manufacturing, transportation, energy, and automation. Below are the technical specifications and key features of this advanced networking solution.

Key Features

• Robust Industrial Design: IP67-rated housing for dust and water resistance, ensuring operation in extreme conditions (-40°C to +75°C).
• High Port Density: 6 x 10/100/1000Base-T(X) RJ45 ports + 6 x 100/1000Base-X SFP slots for flexible fiber or copper connectivity.
• Layer 2 Managed Switch: Supports advanced network management, VLANs, QoS, and redundancy protocols (MRP, RSTP, MSTP).
• Power Redundancy: Dual 24–60 V DC power inputs with reverse polarity protection.
• DIN-Rail Mounting: Easy installation in control cabinets or industrial racks.
• Extended Temperature Range: Operates reliably in temperatures from -40°C to +75°C.

Technical Specifications

General Parameters

• Model: MM20-Z6Z6Z6Z6SAHH
• Standards Compliance: IEEE 802.3, 802.1Q, 802.1p, 802.1D, 802.1w, 802.1s
• Data Rate: 10/100/1000 Mbps (RJ45 ports), 1 Gbps (SFP slots)
• Switching Capacity: 24 Gbps
• Packet Forwarding Rate: 17.8 Mpps
• MAC Address Table: 16,000 entries
• Jumbo Frames: Up to 9,216 bytes

Port Configuration

• Copper Ports: 6 x 10/100/1000Base-T(X) RJ45 ports with auto-negotiation and auto-MDI/MDI-X.
• Fiber Ports: 6 x 100/1000Base-X SFP slots (LC connectors), supporting multimode or single-mode SFPs.

Power Supply

• Input Voltage: 24–60 V DC (dual redundant inputs)
• Power Consumption: Max. 12 W (without SFP modules)
• Protection: Reverse polarity, overvoltage, and short-circuit protection.

Environmental Ratings

• Operating Temperature: -40°C to +75°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5–95% (non-condensing)
• Ingress Protection: IP67 (housing), IP20 (connectors)
• Shock/Vibration: EN 60068-2-6 (vibration), EN 60068-2-27 (shock)

Redundancy & Management

• Protocols: MRP (Media Redundancy Protocol), RSTP, MSTP, SNMPv3, LLDP
• Management Interface: Web-based (HTTP/HTTPS), CLI (SSH/Telnet), SNMP, Hirschmann HiVision™ Suite

Certifications

• Safety: UL 60950-1, EN 60950-1
• EMC: FCC Part 15, CE, EN 61000-6-2/4
• Industrial: IEC 61850-3, IEEE 1613 (electric utility)

Applications

• Factory automation (SCADA, PLC networks)
• Rail and transportation systems
• Oil & gas pipelines
• Wind farms and substations
• Mining and heavy machinery

Warranty & Support

• Warranty: 5-year manufacturer warranty.
• Support: Hirschmann’s global technical support and firmware updates.

The Hirschmann MM20-Z6Z6Z6Z6SAHH combines cutting-edge performance with rugged reliability, making it the go-to choice for industrial networks requiring high-speed data transfer, seamless redundancy, and resilience in extreme conditions. For detailed configuration guides or customization options, consult Hirschmann’s technical documentation or contact authorized distributors.
