Introduction to HONEYWELL LG1093AC01
1. Product Description
HONEYWELL LG1093AC01 is a flame amplifier module specially designed for industrial environments, playing a key role in industrial automation and fire safety fields. Its core function is to accurately monitor and detect flame status with the help of an integrated ultraviolet sensor, providing reliable flame monitoring guarantees for various equipment involving combustion processes, ensuring production safety and preventing fire hazards. Whether it is for controlling the stable combustion state of industrial boilers or detecting flames in gas turbines to avoid damage from unburned gases, the LG1093AC01 can perform excellently, making it an indispensable important component for safe industrial operation.
2. Product Technical Parameters
- Sensor Type: Adopts an ultraviolet sensor, which is extremely sensitive to ultraviolet radiation generated by flames, enabling it to quickly and accurately sense the presence of flames, providing a reliable data source for flame monitoring.
- Input Voltage: Supports 24VDC input, which can be adapted to common industrial DC power supplies, ensuring the stable operation of the module and meeting the power configuration requirements of different industrial scenarios.
- Output Voltage: The output voltage range is 0 ~ 10VDC, which can output flame monitoring results in the form of voltage signals, facilitating signal interaction and processing with other control equipment or systems.
- Communication Interface: Equipped with an RS485 communication interface, which has good communication compatibility and stability, and can be easily connected to industrial networks to realize remote data transmission and sharing, facilitating centralized monitoring and management. Some models also support other communication protocols such as Modbus, further expanding its application range in different industrial automation systems.
- Operating Temperature: The operating temperature range is -10°C to +60°C, which can adapt to temperature changes in most industrial environments. It can work stably whether in high-temperature production workshops or outdoor equipment in cold environments, showing strong environmental adaptability.
- Response Time: Has an extremely short response time. Once a flame appears in the detection area, it can react quickly and quickly transmit flame status information to the subsequent processing system, gaining valuable time for timely control of the combustion process or activation of safety protection measures.
- Transmission Distance: The signal transmission distance between the sensor and the amplifier can reach 330 meters. This long-distance transmission feature ensures stable signal transmission even when the sensor and control module are far apart in large industrial facilities, flexibly meeting the needs of complex industrial layouts.
- Environmental Resistance: The overall structure is designed to be sturdy and durable, with good high-temperature resistance, vibration resistance and anti-interference performance. It can maintain a stable working state in high-temperature, strong vibration and complex electromagnetic interference environments common in industrial production, ensuring the accuracy and reliability of flame monitoring.
- Safety Certification: Has passed a variety of strict safety certifications, suitable for various dangerous industrial scenarios including explosive environments, ensuring the safety of personnel and equipment while complying with relevant industry safety specifications.
3. Usage Method
- Pre-installation Preparation: Conduct a comprehensive assessment of the needs of the use scenario, and determine the appropriate installation location based on factors such as the actual installation space, equipment layout and signal transmission distance. Prepare necessary installation tools such as screwdrivers, wrenches, cables, etc., and ensure that the installation site environment is safe, without flammable and explosive materials and potential risk factors. At the same time, carefully check whether the appearance of the module is damaged and whether the accessories are complete.
- Module Installation: According to the equipment installation manual and on-site planning, fix the LG1093AC01 flame amplifier module at the selected position to ensure that the installation is firm and will not be displaced due to factors such as vibration. Usually, methods such as screw fastening or rail mounting can be adopted, and the installation should be carried out in accordance with the operating specifications of the corresponding installation method.
- Wiring Operation: Use appropriate cables to connect the module to related equipment according to the module’s wiring marks and equipment interface standards. For the sensor input line, accurately connect the ultraviolet sensor cable to the sensor input port of the module to ensure a tight connection and avoid signal transmission interruption or interference. For the communication line, connect RS485 and other communication cables to the communication interface of the module, and make relevant configurations such as terminal resistance settings according to the communication network topology and communication protocol requirements. When connecting the power cord, be sure to pay attention to the positive and negative polarity, and correctly connect the 24VDC power supply to the module’s power port to prevent damage to the module due to reverse connection. After wiring is completed, carefully check each connection point to ensure that the connection is correct and firm.
- Parameter Setting: Set the relevant parameters of the module through programming software or the module’s own setting interface according to specific application scenarios and equipment operation requirements. For example, parameters such as flame detection sensitivity, alarm threshold, and communication baud rate can be set. For specific operations, refer to the module’s user manual and adjust the parameters in accordance with the manual’s guidelines to ensure that the module can accurately adapt to actual application needs.
- System Debugging: After the module installation, wiring and parameter setting are completed and confirmed to be correct, turn on the power of the relevant equipment and carry out system debugging. First, use a simulated flame source or an actual combustion device to generate a flame, and observe whether the module can accurately detect the flame and output corresponding signals. Use professional testing equipment or connect to the control system to check whether the flame status signal output by the module is correctly transmitted and whether the system’s response to changes in flame status meets expectations. If abnormalities are found, it is necessary to promptly check issues such as loose wiring, reasonable parameter settings, and compatibility between the module and equipment until the system operates normally.
4. System Introduction
In the architecture of industrial automation and fire safety systems, the HONEYWELL LG1093AC01 flame amplifier module is in a key data collection and front-end early warning link. It works together with a variety of equipment and systems to build a complete combustion safety monitoring system.
In the industrial production process, when it comes to equipment that requires precise control of the combustion process such as industrial boilers and gas turbines, the LG1093AC01 module monitors the flame status in real time through an ultraviolet sensor. Once abnormal flames are detected, such as flameout or unstable flickering, the module will quickly transmit the abnormal signal to the backend control system, such as a PLC (Programmable Logic Controller), through the communication interface. Based on the preset control logic, the PLC will immediately take corresponding measures, such as cutting off the fuel supply and activating the alarm device, to ensure the safety of the equipment and the production process.
In fire safety systems, the LG1093AC01, as an important component of early fire warning, forms a complete fire monitoring and alarm network with fire alarm controllers and other equipment. When the module detects a flame generated in the early stage of a fire, it will promptly transmit the flame signal to the fire alarm controller. After receiving the signal, the fire alarm controller, on the one hand, triggers the on-site sound and light alarm device to remind people to evacuate; on the other hand, transmits the alarm information to the upper computer monitoring system, facilitating the fire control center to grasp the fire situation in a timely manner and dispatch fire resources for fire fighting and rescue.
Take chemical production enterprises as an example. In their production process, many equipment such as reaction kettles and heating furnaces rely on stable combustion processes to operate. The LG1093AC01 module monitors the flames of these equipment in real time to ensure the stability of the combustion process, avoid production accidents caused by abnormal flames, and ensure the continuity and safety of chemical production. In the fire safety system of large commercial complexes, LG1093AC01 modules are distributed in various areas where fire hazards may exist, constantly monitoring the flame situation, providing reliable early fire warning guarantees for the safety of people’s lives and property. With its reliable performance, the LG1093AC01 is widely used in industrial automation, fire safety and other fields, playing an important role in building a safe and stable industrial operating environment and fire safety guarantee system.
