Introduction to HONEWELL UDA2182-CC1-CC2-NN-N-0000-EE-000
1. Product Description
HONEWELL UDA2182-CC1-CC2-NN-N-0000-EE-000 is a universal digital transmitter designed for industrial process measurement and control. It converts signals from various sensors (e.g., pressure, temperature, flow) into standardized outputs, enabling seamless integration with control systems.
With a user-friendly interface and robust construction, it operates reliably in harsh industrial environments, resisting vibration, moisture, and electromagnetic interference. Its versatility makes it suitable for chemical plants, refineries, and manufacturing facilities where accurate process monitoring is critical.
2. Product Technical Parameters
- Power Supply: 10-30V DC, with reverse polarity protection to prevent wiring errors.
- Input Compatibility: Supports multiple sensor types, including 4-20mA, thermocouples (J, K, T, etc.), RTDs (Pt100), and strain gauges.
- Output Signals: 4-20mA analog output and Modbus RTU digital communication for flexible system integration.
- Accuracy: ±0.05% of span, ensuring precise measurement for critical processes.
- Display: 16-segment LED display with backlight, showing real-time process values and status.
- Operating Temperature: -40°C to +85°C, suitable for extreme industrial conditions.
- Protection Rating: IP66, resistant to dust and high-pressure water jets, ideal for outdoor or wet areas.
- Mounting: Panel, pipe, or DIN rail mounting options for flexible installation.
- Weight: Approximately 500 grams, lightweight for easy handling.
3. Usage Method
- Pre-installation Check: Inspect the transmitter for damage. Verify compatibility with the connected sensor and ensure the power supply matches 10-30V DC.
- Mounting: Install using the chosen method (panel, pipe, or DIN rail), ensuring secure fixation and easy access to the interface.
- Wiring:
-
- Connect the sensor to the input terminals, following polarity guidelines for analog signals.
-
- Link the power supply to the designated terminals and connect outputs to the control system.
- Configuration: Use the front-panel buttons or software (via Modbus) to set input type, measurement range, and output scaling. Calibrate if needed using a reference signal.
- Testing: Power on the device, check the display for correct readings, and verify outputs match the measured values using a multimeter or control system diagnostics.
4. System Introduction
In industrial control systems, UDA2182-CC1-CC2-NN-N-0000-EE-000 acts as a key translator between field sensors and central controllers, ensuring reliable data flow for process optimization.
- Signal Conversion: It transforms raw sensor signals into standardized outputs, minimizing noise and ensuring accurate data transmission over long distances.
- Flexible Integration: Compatible with Honeywell’s Experion PKS and other control systems via analog or digital communication, enabling real-time monitoring and control.
- Local Monitoring: The built-in display allows on-site operators to check process values without relying on a central HMI, facilitating quick troubleshooting.
Common applications include monitoring pressure in chemical reactors, tracking temperature in refinery pipelines, and measuring flow in water treatment plants. Its accuracy and durability help maintain stable processes, reduce waste, and enhance operational efficiency.
