Introduction to HONEYWELL 05701-A-0145
05701-A-0145 Product Overview
The HONEYWELL 05701-A-0145 is a high-precision thermistor temperature sensor belonging to the 05701 series, specifically engineered for accurate temperature measurement in diverse applications. As a reliable sensing component, it utilizes advanced thermistor technology to quickly detect temperature changes and convert them into electrical signals for further processing and control by connected automation systems. This sensor is renowned for its excellent stability and reliability, capable of maintaining precise measurement performance in various environments. Its compact design allows for easy installation in space-constrained locations, making it versatile across multiple sectors including industrial automation, building automation, household appliances, and medical equipment. Seamlessly integrating with Honeywell’s automation systems, the 05701-A-0145 provides critical temperature data support for functions such as temperature control, alarm triggering, and safety protection, ensuring the stable and efficient operation of related equipment and processes.
05701-A-0145 Technical Specifications
-
Product Model: 05701-A-0145
-
Product Type: Thermistor Temperature Sensor (Honeywell 05701 Series)
-
Core Functions: High-precision temperature detection; Rapid temperature change response; Temperature-to-electrical signal conversion; Stable data transmission for system control
-
Measurement Specifications: Temperature Measurement Range: Customizable based on application (typical -40°C to +125°C); Measurement Accuracy: High-precision (meets most industrial application requirements)
-
Power Supply: Operating Voltage: 24VDC (compatible with standard industrial power systems); Power Consumption: Low power design, energy-efficient
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP65
-
Mechanical Details: Dimensions (L×W×H): Approx. 140mm × 210mm × 40mm; Net Weight: Approx. 0.4kg; Mounting Type: Versatile installation (compatible with standard mounting brackets); Connector: 50-pin D-Sub connector
-
System Compatibility: Compatible with Honeywell System 57 controllers and industrial automation systems; Supports standard communication protocols for seamless integration with DCS/PLC
Recommended HONEYWELL Similar Series Models
-
05701-A-0301: Input/output control module for industrial automation systems
-
05701-A-0302: Digital input control module for system expansion
-
05701-A-0303: Analog input control module for precise signal collection
-
05701-A-0304: Analog output control module for actuator control
-
05701-A-0325: Communication module for data transmission between system components
-
05701-A-0326: Interface card module for seamless device connection
-
05701-A-0330: High-integrity relay module with redundant fault protection
-
05701-A-0361: Customizable gas detection control module for specific gas types
-
05704-A-0145: Four-channel control card for 4-20mA sensor signal processing
-
05704-A-0170: Redundant four-way control card for critical monitoring systems
