Introduction to HONEYWELL 05701-A-0282
05701-A-0282 Product Overview
The HONEYWELL 05701-A-0282 is a high-reliability single-channel gas detection control module belonging to the 05701 series, specifically designed for industrial fire and gas monitoring systems. As a critical safety component, it is engineered to collect and process signals from combustible, toxic, or oxygen gas detectors, enabling real-time gas concentration monitoring and alarm triggering. This module supports both 4-20mA and millivolt-level input signals, making it compatible with various types of catalytic and infrared gas sensors. Its robust industrial-grade design ensures stable performance in harsh environments with extreme temperatures, humidity, and electromagnetic interference—common in petrochemical, manufacturing, and food processing industries. The compact modular structure allows for easy installation in System 57 racks, while intuitive LED indicators provide clear status feedback, simplifying on-site commissioning and maintenance. Seamlessly integrating with Honeywell’s industrial automation systems, the 05701-A-0282 plays a vital role in preventing gas leakage hazards and ensuring process safety.
05701-A-0282 Technical Specifications
-
Product Model: 05701-A-0282
-
Product Type: Single-channel Gas Detection Control Module (Honeywell 05701 Series)
-
Core Functions: Gas concentration signal collection and processing; Multi-level alarm threshold setting; Real-time status monitoring; Sensor performance diagnosis
-
Input Specifications: Input Signal Types: 4-20mA analog signal, millivolt (mV) catalytic detection signal; Number of Channels: 1 independent channel
-
Power Supply: Operating Voltage: 24VDC; Power Consumption: Maximum 5W
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP65
-
Mechanical Details: Dimensions (L×W×H): Approx. 140mm × 210mm × 40mm; Net Weight: Approx. 0.4kg; Mounting Type: 19-inch System 57 rack mount; Connector: 50-pin D-Sub connector
-
System Compatibility: Compatible with Honeywell System 57 controllers; Supports MODBUS RTU protocol for DCS/PLC integration; Complies with SIL 2 and IEC 61508 standards
Recommended HONEYWELL Similar Series Models
-
05701-A-0301: Catalytic gas detection control card for combustible gas monitoring
-
05701-A-0302: Digital input control module for gas detection system expansion
-
05701-A-0325: Infrared gas detection control card for toxic gas monitoring
-
05701-A-0330: High-integrity relay module with redundant fault protection
-
05701-A-0351: Infrared gas detection control card with enhanced anti-interference capability
-
05701-A-0361: Customizable gas detection control module for specific gas types
-
05704-A-0121: Four-way relay interface card compatible with 05701 series
-
05704F: Four-channel fire control card for flame and smoke detector input
-
05704-A-0145: 4-channel control card for 4-20mA gas sensor signals
-
05704-A-0170: Redundant four-way control card for critical gas monitoring systems
