Introduction to HONEYWELL 05701-A-0301
05701-A-0301 Product Overview
The HONEYWELL 05701-A-0301 is a versatile basic signal processing module designed for industrial control and process automation systems. It specializes in conditioning and converting analog signals from various industrial sensors (e.g., pressure, temperature, flow transmitters) to ensure precise, stable data transmission to central controllers. Equipped with reliable signal isolation technology, it effectively resists electromagnetic interference and voltage fluctuations in harsh industrial environments. Its compact, standardized design supports 35mm DIN rail mounting, enabling seamless integration into Honeywell control systems and easy maintenance. With essential self-diagnostic functions, it allows real-time operational status monitoring, helping maintenance teams quickly resolve issues and minimize downtime. Suitable for general manufacturing, food processing and auxiliary industrial systems, it provides a cost-effective and reliable signal processing solution.
05701-A-0301 Technical Specifications
-
Product Model: 05701-A-0301
-
Product Type: Basic Signal Processing Module (05701 Series Industrial Control Signal Conditioning)
-
Core Functions: Analog signal conditioning & conversion; Signal isolation for anti-interference; Real-time status monitoring; Basic fault diagnosis & alarm; Stable data transmission to central units
-
Input/Output Specifications: Signal Type: Analog (4-20mA DC, 0-10V DC); Input Channels: 4 single-ended; Output Channels: 4 isolated analog; Conversion Accuracy: ±0.2% of full scale
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typical 4.5W, Max 6.5W
-
Protection Features: Over-voltage protection (up to 36VDC); Short-circuit protection; 2000VAC electrical isolation (input/output & power supply); Anti-EMI (EN 55022 Class A compliant)
-
Environmental Limits: Operating Temp: -30°C to +65°C; Storage Temp: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical Details: Mounting Type: 35mm standard DIN rail; Protection Rating: IP20; Dimensions (L×W×H): Approx. 92mm × 72mm × 38mm; Net Weight: Approx. 0.22kg
-
Compatibility & Certifications: Compatible with Honeywell DCS & PLC systems; Complies with IEC 61131-2, IEC 61010-1; CE, RoHS Certified
Recommended Honeywell Same-Series Models
-
HONEYWELL 05701-A-0302: 8-channel enhanced signal processing module
-
HONEYWELL 05701-A-0303: High-speed signal processing module (response time ≤2ms)
-
HONEYWELL 05701-A-0304: 2500VAC high-isolation signal processing module
-
HONEYWELL 05701-A-0305: Low-power signal processing module for energy-saving systems
-
HONEYWELL 05701-A-0306: Multi-function module supporting analog & digital signals
-
HONEYWELL 05701-A-0307: High-precision signal processing module (±0.1% conversion accuracy)
-
HONEYWELL 05701-A-0308: Safety-rated module for emergency shutdown systems
-
HONEYWELL 05701-A-0309: Digital signal processing module with Modbus RTU communication
-
HONEYWELL 05701-A-0310: Compact module for limited-space installations
-
HONEYWELL 05701-A-0311: Redundant signal processing module for high-reliability systems
-
HONEYWELL 05701-A-0312: Thermocouple-specific signal processing module
-
HONEYWELL 05701-A-0313: RTD signal processing module for high-precision temperature sensing
-
HONEYWELL 05701-A-0314: Industrial-grade module with enhanced corrosion resistance
-
HONEYWELL 05701-A-0315: Extended temperature range module (-40°C to +75°C)
-
HONEYWELL 05701-A-0316: Cost-effective module for general industrial applications
-
HONEYWELL 05701-A-0317: Signal processing module with built-in surge protection
-
HONEYWELL 05701-A-0318: Wireless communication-enabled signal processing module
