Introduction to HONEYWELL 05701-A-0302
05701-A-0302 Product Overview
The HONEYWELL 05701-A-0302 is a high-precision single-channel gas control card belonging to the 05701 series, specifically designed for industrial gas detection and control systems. As a critical component in gas monitoring architectures, it specializes in collecting and processing millivolt-level signals from gas sensors, converting them into standardized data for transmission to central controllers. This module is engineered with high-sensitivity signal processing circuits, ensuring accurate detection of trace gases and reliable performance in harsh industrial environments with temperature fluctuations, humidity, and electromagnetic interference—making it suitable for petrochemical, mining, and industrial manufacturing sectors where gas safety monitoring is crucial. Its compact modular design facilitates easy installation on standard System 57 racks, while intuitive status indicators allow for real-time monitoring of sensor connection and signal transmission status, simplifying on-site troubleshooting and maintenance.
05701-A-0302 Technical Specifications
-
Product Model: 05701-A-0302
-
Product Type: Single-channel Gas Control Card (Honeywell 05701 Series)
-
Core Functions: Millivolt signal collection and processing; Gas sensor signal conversion; Real-time status indication; Compatibility with gas detection system integration
-
Input Specifications: Input Signal Type: Millivolt (mV) signal from gas sensors; Number of Channels: 1 independent channel; Signal Accuracy: ±0.1% FS
-
Power Supply: Operating Voltage: 24VDC; Power Consumption: Typical 2.5W, Maximum 4W
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP67
-
Mechanical Details: Dimensions (L×W×H): Approx. 110mm × 50mm × 120mm; Net Weight: Approx. 0.4kg; Terminal Type: 2.5mm² (14 AWG) field terminals; Mounting Type: System 57 rack plug-in
-
System Compatibility: Compatible with Honeywell industrial gas detection systems; Supports standard industrial communication protocols for seamless data transmission
Recommended HONEYWELL Similar Series Models
-
05701-A-0330: Single-channel gas control card for combustible gas detection
-
05701-A-0351: Single-channel interface card with relay output for gas alarm control
-
05701-A-0360: Single-channel high-isolation gas control card for harsh interference environments
-
05701-A-0370: Single-channel gas control card with alarm logging function
-
05704-A-0121: Four-way relay interface card compatible with 05701 series
-
05704-A-0144: 4-channel digital light source control card for gas sensor auxiliary lighting
-
05704-A-0145: 4-channel control card for 4-20mA gas sensor signals
-
05704F: Four-channel fire control card for flame/smoke detector input
-
05704-A-0122: 8-channel relay interface card for multi-point gas alarm expansion
-
05704-A-0170: Redundant four-way control card for critical gas monitoring systems
