05701-A-0302 Product Introduction
The HONEYWELL 05701-A-0302 is a high-performance single-channel control card, specifically engineered for Honeywell System 57 industrial automation control systems. As a critical component in process control loops, it is mainly designed for catalysis-related industrial scenarios, responsible for receiving and processing field signals, as well as implementing precise control of process parameters such as temperature, pressure, and flow. This module supports both analog and digital input/output signals, enabling flexible adaptation to various field instruments and equipment. Adopting a plug-in modular design, it facilitates easy installation, maintenance, and replacement, seamlessly integrating into the System 57 rack-mounted architecture. Built with high-quality industrial-grade metal housing, it exhibits excellent anti-interference performance and environmental adaptability, maintaining stable and reliable operation in harsh industrial environments with wide temperature fluctuations and electromagnetic interference. It is widely applicable in chemical, petroleum, pharmaceutical, and food processing industries, providing solid support for the efficiency and stability of industrial production processes.
05701-A-0302 Technical Specifications
-
Product Model: 05701-A-0302
-
Product Type: Single-channel Control Card (Honeywell System 57 Series)
-
Core Functions: Catalysis process control; Field signal reception and processing; Precise process parameter regulation; Analog and digital signal compatibility
-
Signal & Connection: Input Signal Range: 0-10V DC or 4-20mA DC; Output Signal Type: Relay output; Connection Mode: Plug-in design (System 57 rack-mounted); Interface Type: Removable screw terminals
-
Electrical Specifications: Operating Voltage: 24VDC; Maximum Power Consumption: 20W; Isolation Voltage: 500VAC (field side and system side); Accuracy: ±0.1%FS; Response Time: Less than 2 seconds
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -55°C to +95°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP65
-
Mechanical Details: Housing Material: Industrial-grade metal; Mounting Type: System 57 rack plug-in; Dimensions: 113mm × 60mm × 25mm; Net Weight: Approx. 0.2kg
-
System Compatibility: Fully compatible with Honeywell System 57 control systems; Suitable for integration into chemical, petroleum, pharmaceutical, food processing, and metallurgical industry control setups
Recommended Honeywell Models
-
05701-A-0301: 05701 series input/output control module, supporting 4-20mA current signal processing
-
05701-A-0303: 05701 series analog input control module with high-precision signal acquisition capability
-
05701-A-0304: 05701 series analog output control module for stable control signal transmission
-
05701-A-0325: 05701 series 32-channel digital input card (24VDC) for multi-signal collection
-
05701-A-0326: 05701 series interface card module for system expansion and signal conversion
-
05701-A-0330: 05701 series 8-channel high-integrity relay module with redundancy protection
-
05701-A-0550: 05701 series control module with multi-protocol communication support
-
CC-PAIH01: Analog input module with HART protocol for intelligent sensor data collection
-
CC-PAOX01: Analog output module for stable actuator control signal transmission
-
51196655-100 ACX633: ACX series power supply module for stable system power supply
-
CC-PWRR01: 20A redundant DC power module for cabinet-level power supply protection
-
CC-PCNT01: C300 control processor module for core industrial process control
-
TC-CCR014: Redundant network interface module ensuring continuous system communication
-
CC-PDIS01: Digital input module with SOE function for event sequence recording
