Introduction to HONEYWELL 05701-A-0326
05701-A-0326 Product Overview
The HONEYWELL 05701-A-0326 is a versatile signal processing module from the 05701 series, engineered for industrial control and process automation applications. It serves as a critical interface between field sensors and central control units, specializing in conditioning and converting analog signals from pressure, temperature, and flow transducers to ensure precise and stable data transmission. Equipped with reliable signal isolation technology, this module effectively mitigates electromagnetic interference and voltage fluctuations common in industrial environments, maintaining consistent performance even in harsh working conditions. Its compact, standardized design supports 35mm DIN rail mounting, enabling seamless integration into Honeywell control systems and simplifying installation and maintenance processes. With built-in self-diagnostic functions, it allows real-time monitoring of operational status, helping maintenance teams quickly identify and resolve issues to minimize system downtime. Suitable for general manufacturing, light industry, and auxiliary power generation systems, the 05701-A-0326 provides a cost-effective and dependable signal processing solution.
05701-A-0326 Technical Specifications
-
Product Model: 05701-A-0326
-
Product Type: Versatile Signal Processing Module (05701 Series)
-
Core Functions: Analog signal conditioning & conversion; Signal isolation for anti-interference; Real-time status monitoring; Basic fault diagnosis; Stable data transmission to central units
-
Input/Output: Signal Type: 4-20mA DC, 0-10V DC (analog); Input Channels: 4 single-ended; Output Channels: 4 isolated analog; Conversion Accuracy: ±0.2% FS
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typ 5W, Max 7W
-
Protection: Over-voltage (up to 36VDC), short-circuit protection; 2000VAC isolation; EN 55022 Class A anti-EMI
-
Environment: Operating Temp: -30°C to +65°C; Storage Temp: -40°C to +85°C; Humidity: 5%-95% (non-condensing); Vibration: 5g (10-500Hz)
-
Mechanical: Mounting: 35mm DIN rail; Protection Rating: IP20; Dimensions: ~95×75×40mm; Weight: ~0.25kg
-
Compatibility: Works with Honeywell DCS & PLC; Complies with IEC 61131-2, IEC 61010-1; CE, RoHS Certified
Recommended Honeywell Same-Series Models
-
05701-A-0327: 8-channel enhanced signal processing
-
05701-A-0328: High-speed module (response time ≤3ms)
-
05701-A-0329: 2500VAC high-isolation signal processing
-
05701-A-0330: Basic signal processing for general industrial use
-
05701-A-0331: Multi-function support for analog & digital signals
-
05701-A-0332: High-precision (±0.1% conversion accuracy)
-
05701-A-0333: Safety-rated for emergency shutdown systems
-
05701-A-0334: Digital processing with Modbus RTU communication
-
05701-A-0335: Compact design for limited-space installations
-
05701-A-0336: Redundant module for high-reliability systems
-
05701-A-0337: Thermocouple-specific signal processing
-
05701-A-0338: RTD signal processing for precision temperature sensing
-
05701-A-0339: Industrial-grade with enhanced corrosion resistance
-
05701-A-0340: Extended temperature range (-40°C to +75°C)
-
05701-A-0341: Low-power for energy-saving systems
-
05701-A-0342: Signal processing with built-in surge protection
-
05701-A-0343: Wireless communication-enabled module
-
05701-A-0344: 16-channel expanded signal processing
