05701-A-0330 Product Introduction
The HONEYWELL 05701-A-0330 is a high-integrity relay module belonging to the 05701 series, specifically designed for critical switching control applications in industrial automation systems. It serves as a key component to precisely control on-site devices like motors, valves, and lamps, while offering reliable redundancy and fault protection to ensure overall system stability and operational safety. Featuring a dual SPCO (Single Pole Changeover) design, the module achieves redundancy backup to minimize downtime risks from single-point failures. Its compact plug-in structure allows easy installation and seamless integration with 05701 series rack-mounted architectures. Constructed with industrial-grade components, it delivers excellent anti-interference performance and complies with international standards such as SIL 2 and IEC 61508, making it suitable for automotive manufacturing, chemical, petroleum, and food processing industries.
05701-A-0330 Technical Specifications
-
Product Model: 05701-A-0330
-
Product Type: High-integrity Relay Module (Honeywell 05701 Series)
-
Core Functions: On-site device switching control; Dual SPCO redundancy protection; Fault isolation and alarm; High-reliability signal switching; SIL 2 & IEC 61508 compliance
-
Signal & Connection: Relay Contact Type: Dual SPCO; Connection Mode: Plug-in (compatible with 05701 series rack); Interface: Relay output terminals
-
Electrical Specifications: Operating Voltage: 24VDC; Maximum Load Current per Channel: 10A; Isolation: Enhanced inter-channel electrical isolation; Certification: CE, SIL 2, IEC 61508
-
Environmental Ratings: Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP20 (in standard control cabinet)
-
Mechanical Details: Housing Material: Industrial-grade high-strength plastic; Mounting Type: 05701 series rack-mounted; Dimensions: 100mm × 60mm × 22mm; Net Weight: Approx. 0.18kg
-
System Compatibility: Fully compatible with Honeywell 05701 series control systems; Suitable for automotive, chemical, petroleum, food processing, and packaging machinery control setups
Recommended Honeywell Models
-
05701-A-0301: Single-channel control card supporting 4-20mA current signal processing and conversion
-
05701-A-0302: Single-channel control card designed for catalytic process control
-
05701-A-0303: Analog input control module with high-precision signal acquisition
-
05701-A-0304: Analog output control module for stable control signal transmission
-
05701-A-0325: DC input card for discrete signal collection
-
05701-A-0326: Field interface card for sensor input without relay function
-
05701-A-0327: Dual SPCO relay card with fault and inhibit functions
-
05701-A-0328: Triple SPCO relay card for multi-channel switching control
-
05701-A-0329: Triple DPCO relay card with dual-channel redundancy protection
-
05701-A-0312: Modbus interface module supporting RS 485/RS 422 communication
-
05701-A-0313: Modbus interface module with RS 232 communication port
-
05701-A-0314: Event printing module with RS 232 interface
-
05701-A-0405: AC-DC power supply unit for 16-channel systems
-
05701-A-0550: Calibration plug for 05701 series analysis systems
