Introduction to HONEYWELL 05701-A-0330
05701-A-0330 Product Introduction
The HONEYWELL 05701-A-0330 is a high-integrity relay module under the Honeywell 05701 series, specifically engineered for critical applications in industrial automation and control systems. As a core component for device control and protection, it features a dual SPCO (Single Pole Changeover) design, providing reliable redundancy and fault protection to ensure the stability and safety of industrial processes. This module is designed to precisely control the operation of various on-site devices such as motors, lamps, and valves, while realizing signal isolation and amplification to enhance the anti-interference capability of the control system. With a compact and rugged industrial-grade structure, it facilitates easy installation and integration into existing control systems. It complies with SIL 2 and IEC 61508 international safety standards, making it widely applicable in automotive manufacturing, food processing, petrochemical, power systems, and other industrial fields that demand high reliability of device control.
05701-A-0330 Technical Parameters
-
Product Model: 05701-A-0330
-
Product Type: High-Integrity Relay Module (Honeywell 05701 Series)
-
Core Functions: 8-channel relay output control; Dual SPCO redundant design; Fault protection for industrial processes; Signal isolation and amplification; Precise on-site device control
-
Connection Specifications: 8-channel relay output terminals; Standard industrial terminal connections; Compliant with industrial automation communication standards
-
Electrical Specifications: Power Supply: 24VDC; Relay Load Current: 10A per channel max; Relay Contact Type: SPDT (Single Pole Double Throw); Certifications: SIL 2, IEC 61508, CE compliant
-
Environmental Ratings: Operating Temperature: -20°C to 60°C; Storage Temperature: -40°C to 85°C; Relative Humidity: 5% – 95% (non-condensing)
-
Mechanical Details: Housing Material: Industrial-grade high-strength plastic; Dimensions: 100mm × 60mm × 22mm; Installation: DIN rail mounting
-
System Compatibility: Fully compatible with Honeywell 05701 series industrial control systems; Suitable for automotive manufacturing, food processing, petrochemical, power system setups
Recommended Honeywell Same-Series Models
-
05701-A-0301: Input/output control module for integrated signal processing
-
05701-A-0302: Digital input control module for discrete signal collection
-
05701-A-0303: Analog input control module for process parameter monitoring
-
05701-A-0304: Analog output control module for control signal transmission
-
05701-A-0325: Communication module for system data exchange
-
05701-A-0326: Interface card module for system expansion and connection
-
05701-A-0328: Triple SPCO relay card for multi-channel fault protection control
-
05701-A-0329: Triple DPCO relay card for dual-channel redundant control
-
05701-A-0339: Main alarm update panel for system alarm management
-
05701-A-0550: Calibration plug for 05701 series system calibration
-
05701-B-0001: Enhanced relay module with extended load capacity
-
05701-C-0002: Industrial-grade relay module with explosion-proof performance
-
05701-A-0401: High-temperature resistant relay module for harsh environments
-
05701-A-0425: Low-power relay module for long-term continuous operation
-
05701-D-0001: Relay module with real-time fault monitoring function
