Introduction to HONEYWELL 05701-A-0361
05701-A-0361 Product Overview
The HONEYWELL 05701-A-0361 is a high-performance single-channel gas detection control card belonging to the 05701 series, specifically designed for industrial safety monitoring systems. Leveraging advanced catalytic combustion detection technology, it specializes in detecting combustible, toxic, and inert gases, providing reliable early warning of gas leaks to prevent explosions and fire accidents. As a core component in gas safety management, this module not only accurately collects and processes gas concentration signals but also integrates discrete input/output functions and flame detection capabilities, enhancing its versatility in industrial automation and safety control scenarios. Its modular and compact design facilitates easy installation on Honeywell System 57 racks, while clear status indicators and user-friendly configuration tools simplify on-site commissioning and maintenance. Engineered with an IP65 protection rating, it maintains stable performance in harsh industrial environments such as dusty, humid, and high-temperature settings common in petroleum, chemical, and metallurgical industries.
05701-A-0361 Technical Specifications
-
Product Model: 05701-A-0361
-
Product Type: Single-channel Gas Detection Control Card (Honeywell 05701 Series, System 57 Compatible)
-
Core Functions: Detection of combustible/toxic/inert gases via catalytic combustion technology; Discrete input/output control; Flame detection and induction; Gas concentration signal collection and processing; Remote monitoring support
-
Signal & Connection: Compatible Signal Type: 4-20mA; Communication Protocols: RS485, RS232, CAN; Connector: 50-pin D-Sub connector; Installation Standard: DIN 3106
-
Electrical Specifications: Operating Voltage: 24VDC; Power Consumption: 5W; Current: 24mA
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Protection Rating: IP65
-
Mechanical Details: Dimensions (L×W×H): 140mm × 210mm × 40mm; Net Weight: Approx. 0.5kg; Housing Material: High-quality industrial-grade material
-
System Compatibility: Fully compatible with Honeywell System 57; Seamlessly integrates with DCS/PLC systems; Suitable for petroleum, chemical, metallurgical, and food processing industry control setups
Recommended HONEYWELL Similar Series Models
-
05701-A-0301: Catalytic-type gas detection control card for receiving and processing 4-20mA field instrument signals
-
05701-A-0302: Digital input control module for combustible gas detection system expansion
-
05701-A-0330: High-integrity relay module with dual SPCO design and redundant fault protection
-
05701-A-0325: Infrared single-channel gas detection control card for detecting combustible, toxic and inert gases
-
05701-A-0328: Infrared gas detection control card with high precision and sensitivity
-
05701-A-0303: Analog input control module for precise signal collection
-
05701-A-0304: Analog output control module for actuator driving
-
05701-A-0326: Interface card module for seamless connection of external devices to Series 57 systems
-
05704-A-0121: Four-way relay interface card compatible with 05701 series modules
-
05704-A-0145: 4-channel control card specialized in 4-20mA sensor signal processing
-
05704-A-0170: Redundant four-way control card for critical safety monitoring systems
-
05701-A-0283: 4-20mA sensor driver module for signal conditioning and power supply
-
05701-A-0550: Dedicated calibration plug for calibrating Series 57 gas detection system sensors
