05701-A-0361 Product Overview
The HONEYWELL 05701-A-0361 is a versatile and reliable signal processing module from the 05701 series, designed for a wide range of industrial control and process automation applications. It serves as a crucial bridge between field sensors and central control units, specializing in conditioning and converting analog signals from pressure, temperature, and flow transducers to ensure accurate and stable data transmission. Equipped with effective signal isolation technology, this module can effectively resist electromagnetic interference and voltage fluctuations common in complex industrial environments, maintaining consistent performance in harsh working conditions. Its compact and standardized 35mm DIN rail-mounted design allows for seamless integration into various Honeywell control system architectures, simplifying installation and on-site maintenance processes. Featuring built-in self-diagnostic capabilities, it provides real-time monitoring of operational status, helping maintenance personnel quickly identify and resolve potential faults to minimize system downtime.
05701-A-0361 Technical Specifications
-
Product Model: 05701-A-0361
-
Product Type: Versatile Signal Processing Module (05701 Series)
-
Core Functions: Analog signal conditioning & conversion; Signal isolation for anti-interference; Real-time operational status monitoring; Basic fault diagnosis & alarm; Stable data transmission to central controllers
-
Input/Output: Signal Type: 4-20mA DC, 0-10V DC (analog); Input Channels: 4 single-ended channels; Output Channels: 4 isolated analog channels; Conversion Accuracy: ±0.2% FS
-
Power Supply: Operating Voltage: 24VDC (±10%); Power Consumption: Typical 5W, Maximum 7W
-
Protection: Over-voltage protection (up to 36VDC); Short-circuit protection (per-channel); 2000VAC electrical isolation; EN 55022 Class A anti-EMI compliance
-
Environment: Operating Temperature: -30°C to +65°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 5% – 95% (non-condensing); Vibration Resistance: 5g (10-500Hz)
-
Mechanical: Mounting Type: 35mm standard DIN rail; Protection Rating: IP20; Dimensions (L×W×H): Approx. 95mm × 75mm × 40mm; Net Weight: Approx. 0.25kg
-
Compatibility: Compatible with Honeywell DCS & PLC systems; Complies with IEC 61131-2, IEC 61010-1 standards; CE, RoHS Certified
Recommended Honeywell Same-Series Models
-
05701-A-0362: 8-channel enhanced signal processing
-
05701-A-0363: High-speed module (response time ≤3ms)
-
05701-A-0364: 2500VAC high-isolation signal processing
-
05701-A-0365: Low-power module for energy-saving systems
-
05701-A-0366: Multi-function support for analog & digital signals
-
05701-A-0367: High-precision module (±0.1% conversion accuracy)
-
05701-A-0368: Safety-rated for emergency shutdown systems
-
05701-A-0369: Digital processing with Modbus RTU communication
-
05701-A-0370: Compact design for limited-space installations
-
05701-A-0371: Redundant module for high-reliability systems
-
05701-A-0372: Thermocouple-specific signal processing
-
05701-A-0373: RTD signal processing for precision temperature sensing
-
05701-A-0374: Industrial-grade with enhanced corrosion resistance
-
05701-A-0375: Extended temperature range (-40°C to +75°C)
-
05701-A-0376: Cost-effective for general industrial applications
-
05701-A-0377: Built-in surge protection
-
05701-A-0378: Wireless communication-enabled module
-
05701-A-0379: 16-channel expanded signal processing
-
05701-A-0380: Signal processing with Ethernet communication
