Introduction to HONEYWELL 05701-A-0511
05701-A-0511 Product Introduction
The HONEYWELL 05701-A-0511 is an industrial-grade digital temperature controller belonging to the 05701 series, specifically engineered for precise temperature measurement and control in various industrial automation processes. As a core component in thermal control loops, it is designed to real-time monitor temperature signals from field sensors, implement advanced control algorithms such as PID, and regulate actuators to maintain stable process temperatures. This controller supports multiple output modes including relay and analog output, enabling flexible adaptation to different types of heating or cooling equipment. Equipped with practical functions like trend recording and alarm notification, it provides timely alerts for abnormal temperature fluctuations, ensuring the safety and efficiency of production processes. Adopting a rugged and durable design, it can operate stably in harsh industrial environments with temperature variations, vibration, and electromagnetic interference.
05701-A-0511 Technical Specifications
-
Product Model: 05701-A-0511
-
Product Type: Digital Temperature Controller (Honeywell 05701 Series)
-
Core Functions: Precise temperature measurement and control; PID control algorithm; Trend recording; Alarm notification for abnormal temperature; Multiple output mode support
-
Signal & Connection: Input Range: -40°C to +125°C; Output Mode: Relay output or analog output; Communication Protocol: RS485, Modbus; Installation Mode: DIN rail mounting or screw mounting
-
Electrical Specifications: Power Supply: 24 VAC/DC; Power Consumption: 10 W; Resolution: 0.1°C; Accuracy: ±0.5% full scale; Response Time: 1 second
-
Environmental Ratings: Operating Temperature: -20°C to +60°C; Storage Temperature: -40°C to +85°C; Relative Humidity: 0% – 95% (non-condensing); Vibration Resistance: 5g up to 2kHz; Shock Resistance: 15g
-
Mechanical Details: Housing Material: High-quality industrial-grade plastic; Dimensions: Compact design (optimized for control cabinet installation); Net Weight: Approx. 150g; Protection Rating: IP20
-
System Compatibility: Fully compatible with Honeywell 05701 series control systems; Suitable for integration into petroleum and natural gas, chemical, pharmaceutical, food processing, and industrial automation control setups
Recommended Honeywell Models
-
05701-A-0301: Single-channel control card supporting 4-20mA current signal processing and conversion
-
05701-A-0302: Single-channel control card designed for catalytic process control
-
05701-A-0303: Analog input control module with high-precision signal acquisition
-
05701-A-0304: Analog output control module for stable control signal transmission
-
05701-A-0309: Master station alarm update module kit
-
05701-A-0312: Modbus interface module supporting RS 485/RS 422 communication
-
05701-A-0313: Modbus interface module with RS 232 communication port
-
05701-A-0314: Event printing module with RS 232 interface
-
05701-A-0325: 32-channel DC input card for discrete signal collection
-
05701-A-0326: Single-channel field interface card for sensor signal input (no relay function)
-
05701-A-0327: Dual SPCO relay card with fault and inhibit functions
-
05701-A-0328: Triple SPCO relay card for multi-channel switching control
-
05701-A-0329: Triple DPCO relay card with dual-channel redundancy protection
-
05701-A-0330: High-integrity dual SPCO relay card with fault and inhibit functions
-
05701-A-0339: Main alarm update panel
-
05701-A-0361: Engineering card for system configuration and maintenance
-
05701-A-0405: AC-DC power supply unit for 16-channel systems
-
05701-A-0406: AC-DC power supply unit for 8-channel systems
-
05701-A-0515: 16-channel sub-rack with rear access capability
-
05701-A-0550: Calibration plug for 05701 series analysis systems
