05701-A-0550 Product Overview
The HONEYWELL 05701-A-0550 is a dedicated calibration plug specifically engineered for Honeywell’s System 57 gas detection systems. As an essential auxiliary tool for maintaining measurement accuracy, it simulates specific gas concentration signals to calibrate system sensors and measurement circuits, ensuring the reliability of gas monitoring data. It also supports system performance testing, enabling technicians to verify key indicators like response speed and linearity, which streamlines fault diagnosis and troubleshooting processes. Featuring a user-friendly plug-and-play design, it allows for quick operation without complex configurations, effectively reducing maintenance time and labor costs. With an IP67 protection rating and corrosion-resistant stainless steel housing, this calibration plug adapts well to harsh industrial environments such as dusty, humid, and high-temperature settings in petroleum, chemical, and metallurgical industries. Its 24VDC operating voltage and low power consumption (less than 20W) ensure seamless integration with standard industrial power systems.
05701-A-0550 Technical Specifications
-
Product Model: 05701-A-0550
-
Product Type: Calibration Plug (Honeywell 05701 Series, for System 57 Gas Detection Systems)
-
Core Functions: Simulates gas concentration signals for sensor calibration; Verifies system performance indicators (response speed, linearity); Assists in fault diagnosis and troubleshooting
-
Signal & Connection: Output Signal: Precision gas concentration simulation signal; Output Signal Type: 4-20mA; Connection: 5-pin DIN connector; Installation Type: Plug-in design
-
Electrical Specifications: Operating Voltage: 24VDC; Power Consumption: Less than 20W; Insulation Resistance: ≥100MΩ; Withstand Voltage: AC 500V for 1 minute
-
Environmental Ratings: Operating Temperature: -40°C to +85°C; Storage Temperature: -55°C to +125°C; Relative Humidity: 0% – 95% (non-condensing); Protection Rating: IP67; Housing Material: Corrosion-resistant stainless steel
-
Mechanical Details: Dimensions: 144mm × 102mm × 44mm; Net Weight: 0.5kg; Connection Thread: G1/4 male thread
-
System Compatibility: Fully compatible with Honeywell System 57 gas detection systems; Suitable for integration into petroleum, chemical, and metallurgical industry control setups
