05701-A-0550 Product Overview
The HONEYWELL 05701-A-0550 is a high-performance I/O interface module belonging to the System 57 product family, specifically engineered for industrial automation and process control systems. It serves as a vital bridge between field devices (such as sensors and actuators) and central control units, enabling reliable transmission and processing of both digital and analog signals. Built with robust industrial-grade components and effective electromagnetic interference shielding, this module maintains stable operation in harsh industrial environments with temperature variations, humidity fluctuations, and electrical noise. It seamlessly integrates with Honeywell’s System 57 control platforms, widely applied in petrochemical plants, power generation facilities, and manufacturing lines to enhance the efficiency and reliability of control system operations.
05701-A-0550 Technical Specifications
-
Product Model: 05701-A-0550
-
Product Type: I/O Interface Module (System 57 Series)
-
Core Functions: Digital and analog signal transmission, field device-central controller communication, signal conditioning, electromagnetic interference suppression, fault status monitoring
-
Signal Specifications: Input channels: 8 digital input channels; Output channels: 4 relay output channels; Analog signal support: 4-20mA current signal, 0-10V voltage signal; Signal response time: ≤1ms
-
Power Supply: Operating voltage: 24VDC ±10%; Power consumption: Typical 5W, Maximum 8W; Current consumption: ≤350mA
-
Protection Features: Short-circuit protection for output channels; Over-voltage protection; Reverse polarity protection; Anti-interference: Complies with IEC 61000-4 standards
-
Environmental Limits: Operating temperature: -20°C to +65°C; Storage temperature: -40°C to +85°C; Relative humidity: 5% – 95% (non-condensing); Protection rating: IP40
-
Mechanical Details: Mounting type: DIN rail mounting / System 57 rack compatible; Dimensions (L×W×H): 130mm × 80mm × 60mm; Net weight: Approx. 0.35kg; Enclosure material: Flame-retardant ABS
-
Compatibility & Certifications: Seamlessly integrates with Honeywell System 57 control systems; Certifications: CE, UL, RoHS Compliant
Recommended HONEYWELL Same-Series Models
-
HONEYWELL 05701-A-0325: DC input card for receiving and processing DC signals from field devices
-
HONEYWELL 05701-A-0326: Field interface card facilitating stable signal transmission between system components
-
HONEYWELL 05701-A-0330: High-integrity relay module providing redundant fault protection for critical applications
-
HONEYWELL 05701-A-0351: Infrared gas detection control card specialized in hazardous area gas monitoring
-
HONEYWELL 05701-A-0361: Multi-functional module integrating discrete I/O and flame detection functions
-
HONEYWELL 05701-A-0405: 16-way AC-DC power supply unit for powering System 57 components
-
HONEYWELL 05701-A-0303: Analog input module for high-precision acquisition of 4-20mA/0-10V sensor signals
-
HONEYWELL 05701-A-0304: Analog output module transmitting standardized control signals to actuators
-
HONEYWELL 05704-A-0121: Quad relay interface card with 4 independent SPDT relays for small-scale control
-
HONEYWELL 05704-A-0131: 16-channel relay assembly enabling large-scale system control
-
HONEYWELL 05704-A-0145: Four-channel analog input card for processing pressure/temperature sensor signals
-
HONEYWELL 05701-A-0511: 16-way rear access rack for convenient field wiring in System 57 setups
