05704-A-0145 Product Overview
The HONEYWELL 05704-A-0145 is a high-precision four-channel analog input control card under the System 57 product family, specifically designed for industrial automation and gas detection systems. It serves as a vital signal bridge, capable of simultaneously receiving 4-20mA standard industrial signals from up to four field transmitters (e.g., pressure, temperature, flow, and gas sensors) and converting them into digital data via 12-bit high-precision A/D conversion for the central control unit. Featuring channel-to-channel electrical isolation, 1000V DC isolation between field and system sides, and comprehensive short-circuit and open-circuit protection, this compact module maintains stable performance in harsh industrial environments with strong electromagnetic interference. It supports hot-swappable installation for easy maintenance and seamlessly integrates with Honeywell System 57 control platforms, widely applied in petrochemical plants, water treatment facilities, and high-risk gas monitoring scenarios to ensure reliable process supervision and operational safety.
05704-A-0145 Technical Specifications
-
Product Model: 05704-A-0145
-
Product Type: Four-Channel Analog Input Control Card (System 57 Series)
-
Core Functions: 4-20mA analog signal acquisition, 12-bit A/D conversion, electrical isolation protection, short-circuit/open-circuit protection, hot-swappable maintenance, Modbus RTU communication support
-
Signal Specifications: Input signal type: 4-20mA current signal (supports 2-wire/3-wire transmitters); Number of channels: 4 independent isolated channels; A/D conversion accuracy: 12-bit (±0.1% full-scale error); Measurement range: 0 to 25mA (linear); Maximum line resistance: 500Ω (including sensor)
-
Power Supply: Operating voltage: 18VDC to 32VDC; Loop-powered output voltage: Isolated 24V ±5%, max 25mA; Power consumption: Typical 7.5W, Maximum 8.3W
-
Protection Features: Short-circuit protection; Open-circuit voltage protection (±50V); Isolation breakdown voltage: >1000V DC (field to system side), 500V AC (channel to channel); Anti-vibration/shock: 10-2000Hz@5g RMS, 100g@11ms pulse
-
Environmental Ratings: Operating temperature: -20°C to +60°C; Storage temperature: -25°C to +70°C; Relative humidity: 5% – 95% (non-condensing); Protection rating: IP67
-
Mechanical & Installation: Mounting type: System 57 standard rack plug-in type; Dimensions (L×W×H): 172mm × 25mm × 132mm; Net weight: Approximately 0.17kg; Front panel indicators: A1/A2/A3 alarm LEDs and fault LED per channel
-
Key Features: High-density 4-channel design; High-precision signal conversion; Comprehensive isolation protection; Hot-swappable for convenient maintenance; Online parameter configuration via System 57 configuration software
-
Compatibility: Seamlessly integrates with Honeywell System 57 control systems; Supports Modbus RTU protocol via RS485 interface; Compatible with various industrial transmitters and gas sensors
-
Applications: Industrial automation systems, gas detection systems, petrochemical plants, water treatment facilities, power generation facilities, process safety systems, pressure/temperature/flow monitoring
Recommended HONEYWELL Same-Series Models
-
HONEYWELL 05704-A-0121: Quad relay interface card with 4 independent SPDT relays, ideal for small-scale multi-device control
-
HONEYWELL 05704-A-0131: 16-channel relay interface assembly (12 SPCO, 4 SPST), enabling large-scale relay control for complex systems
-
HONEYWELL 05701-A-0301: Single-channel control card, specialized in high-precision single-signal acquisition and processing
-
HONEYWELL 05701-A-0325: DC input card, dedicated to receiving and processing DC input signals from field devices
-
HONEYWELL 05701-A-0326: Field interface card, facilitating stable signal transmission between system components
-
HONEYWELL 05701-A-0330: High-integrity relay module, providing redundant fault protection for critical control applications
-
HONEYWELL 05701-A-0351: Infrared gas detection control card, specialized in hazardous area gas concentration monitoring
-
HONEYWELL 05701-A-0361: Multi-functional industrial automation module, integrating discrete I/O and flame detection functions
-
HONEYWELL 05701-A-0405: 16-way AC-DC power supply unit, supplying stable power for System 57 components
-
HONEYWELL 05701-A-0511: 16-way rear access rack, designed for convenient field wiring connections in System 57 systems
-
HONEYWELL 05701-A-0303: Analog input control module, supporting high-precision acquisition of 4-20mA/0-10V sensor signals
-
HONEYWELL 05701-A-0304: Analog output control module, reliable for transmitting standardized control signals to actuators
